Replacement Belts
We also carry a complete line of specialized belt kits for specific VCR makes and models. To inquire about
the correct belt kit for your model, visit Parts Finder
For VCR owners, another option to consider is our tune-up kits, which generally consist of all new belts,
new idler or idler tire, and a new pinch roller. Visit Tune-Up Kits
You may be wondering how to measure the sizes of your existing belts. Click here
to find out how.
General Belt Kits
Replacement Square Belts
Replacement Flat Belts
Replacement Turntable Belts
How to Measure Belts
|
General VCR Drive and Loading Belt Kit
|
|
Contains the 10 most popular VCR square capstan/idler and loading belts
|
|
Includes one each of the following sizes:
SBL2.65, SBL3.2, SBL4.2, SBL6.7, SBL7.8, SBL8.2, SBL8.7, SBL9.1, SBL10.0, SBL10.7 |
VCLB Kit
Your Price $9.95
|
|
|
General VCR Loading Belt Kit |
 |
Contains the 10 most popular VCR square loading belts |
|
Includes one each of the following sizes:
SBL2.4, SBL2.5, SBL2.65, SBL2.9, SBL3.0, SBL3.2, SBL3.4, SBL3.6, SBL4.0, SBL4.2
|
VLB Kit
Your Price $9.95
|
|
|
General VCR Flat
Belt Kit |
|
Contains the 7 most popular flat belts used in VCRs |
|
Includes one each of the following sizes:
FBM9.6, FBM9.9, FBM10.2, FBM10.5, FBM10.7, FBM11.0, FBM12.1 |
|
VFBK-1 Kit
Your Price $8.95
|
|
|
General Cassette Deck Belt Kit
|
|
Contains the 10 most popular SQUARE belts used in audio cassette decks
|
|
Includes one each of the following sizes:
SBS2.6, SBS3.4, SBS4.65, SBS5.1, SBS7.5, SBS8.0, SBS8.6, SBS9.8, SBS11.0, SBS12.4
|
CBK Kit
Your Price $7.95
|
|
|
General Cassette FLAT BELT Kit
|
|
Contains the 7 most popular FLAT belts used in cassette decks
|
|
Includes one each of the following sizes:
FBS8.0, FBS9.0, FBS9.6, FBS9.9, FBS10.5, FBS11.0, FBS12.1
(Scroll down for our Deluxe 11-piece Cassette Flat Belt Kit, below)
|
|
CFBK-1 Kit
Your Price
$7.95
|
|
|
Deluxe Cassette FLAT BELT Kit
|
|
Contains the 11 most popular FLAT belts used in cassette decks
|
|
Includes one each of the following sizes:
FBS7.0, FBS7.5, FBS8.0, FBS8.4, FBS9.0, FBS9.6, FBS9.9,
FBS10.5, FBS10.7, FBS11.0, FBS12.1
|
|
DCFBK-1 Kit
Your Price
$9.95
|
|
|
General CD-Player Belt Kit
|
|
Contains the 10 most popular belts used in CD Players
|
|
Includes one each of the following sizes:
SBM2.5, SBM3.0, SBM3.2, SBM3.4, SBM3.6, SBM4.0, SBM4.2, SBM4.5, SBM5.0, SBM5.6
|
|
CDBK-1 Kit
Your Price
$8.95
|
|
|
General 8-Track
Player Belt Kit |
|
Contains the 7 most popular flat belts used in 8-Track Players |
|
Includes one each of the following sizes:
FBM9.0, FBM9.6, FBM10.2, FBM11.0, FBM12.1, FBM13.3, FBM14.0 |
|
8TBK-1 General 8-Track Belt Kit
Your Price $7.95
(Scroll down for our Deluxe 12-piece 8-Track Belt Kit, below)
For more on 8-track equipment,
visit www.keepontrackin.bravepages.com
or www.8trackheaven.com
|
|
|
Deluxe
8-Track
Player Belt Kit |
|
Contains the 12 most popular flat belts used in 8-Track Players |
|
Includes one each of the following sizes:
FBM9.0, FBM9.6, FBM9.9, FBM10.2, FBM10.5, FBM10.7, FBM11.0,
FBM11.5, FBM12.1, FBM12.5, FBM13.3, FBM14.0 |
|
8TDBK-1 Deluxe 8-track Belt Kit
Your Price $10.95
For more on 8-track equipment,
visit www.keepontrackin.bravepages.com
or www.8trackheaven.com
|
|
Replacement Square Belts
How to Measure Belts
SBO (Square Belt Other) belts are extra-small and typically used in smaller cassette decks, especially Walkman Type. These are the thinnest square belts we carry - 1mm in thickness (just slightly thicker than a credit card). I.C. (inside circumference) is shown in inches.
|
|
Part # |
I.C.* |
Thickness |
Price ea |
Purchase
|
|
SBO1.55 |
1.55 |
.039" (1mm) |
$1.05
|
|
|
SBO2.5 |
2.5 |
.039" (1mm) |
$1.05 |
|
|
SBO3.2 |
3.2 |
.039" (1mm) |
$1.05 |
|
|
SBO3.7 |
3.7 |
.039" (1mm) |
$1.05 |
|
|
SBO4.0 |
4.0 |
.039" (1mm) |
$1.05 |
|
|
SBO4.3 |
4.3 |
.039" (1mm) |
$1.05 |
|
|
SBO4.7 |
4.7 |
.039" (1mm) |
$1.05 |
|
|
SBO5.0 |
5.0 |
.039" (1mm) |
$1.05 |
|
|
SBO5.2 |
5.2 |
.039" (1mm) |
$1.05 |
|
|
SBO5.7 |
5.7 |
.039" (1mm) |
$1.05 |
|
|
SBO6.0 |
6.0 |
.039" (1mm) |
$1.05 |
|
|
SBO6.6 |
6.6 |
.039" (1mm) |
$1.05 |
|
|
SBO7.2 |
7.2 |
.039" (1mm) |
$1.05 |
|
|
SBO8.0 |
8.0 |
.039" (1mm) |
$1.15 |
|
|
SBO8.6 |
8.6 |
.039" (1mm) |
$1.15 |
|
|
SBO9.0 |
9.0 |
.039" (1mm) |
$1.15 |
|
|
SBO9.7 |
9.7 |
.039" (1mm) |
$1.15 |
|
|
SBO10.2 |
10.2 |
.039" (1mm) |
$1.15 |
|
|
SBO10.5 |
10.5 |
.039" (1mm) |
$1.15 |
|
SBS (Square Belt Small) belts are typically used in cassette decks, and in some VCRs. These belts are 0.046 inches or 1.2mm thick (slightly thinner than a U.S. dime). I.C. (inside circumference) is shown in inches.
|
|
Part # |
I.C.* |
Thickness |
Price ea |
Purchase |
|
SBS2.0 |
2.0 |
.046" (1.2mm) |
$1.05 |
|
|
SBS2.2 |
2.2 |
.046" (1.2mm) |
$1.05 |
|
|
SBS2.4 |
2.4 |
.046" (1.2mm) |
$1.05 |
|
|
SBS2.6 |
2.6 |
.046" (1.2mm) |
$1.05 |
|
|
SBS3.0 |
3.0 |
.046" (1.2mm) |
$1.05 |
|
|
SBS3.2 |
3.2 |
.046" (1.2mm) |
$1.05 |
|
|
SBS3.5 |
3.5 |
.046" (1.2mm) |
$1.05 |
|
|
SBS4.0 |
4.0 |
.046" (1.2mm) |
$1.05 |
|
|
SBS4.3 |
4.3 |
.046" (1.2mm) |
$1.05 |
|
|
SBS4.6 |
4.6 |
.046" (1.2mm) |
$1.05 |
|
|
SBS5.1 |
5.1 |
.046" (1.2mm) |
$1.05 |
|
|
SBS5.6 |
5.6 |
.046" (1.2mm) |
$1.05 |
|
|
SBS6.2 |
6.2 |
.046" (1.2mm) |
$1.05 |
|
|
Part # |
I.C.* |
Thickness |
Price ea |
Purchase |
|
SBS6.7 |
6.7 |
.046" (1.2mm) |
$1.05 |
|
|
SBS7.0 |
7.0 |
.046" (1.2mm) |
$1.05 |
|
|
SBS7.4 |
7.4 |
.046" (1.2mm) |
$1.05 |
|
|
SBS8.0 |
8.0 |
.046" (1.2mm) |
$1.15 |
|
|
SBS8.4 |
8.4 |
.046" (1.2mm) |
$1.15 |
|
|
SBS8.9 |
8.9 |
.046" (1.2mm) |
$1.15 |
|
|
SBS9.5 |
9.5 |
.046" (1.2mm) |
$1.15 |
|
|
SBS10.0 |
10.0 |
.046" (1.2mm) |
$1.15 |
|
|
SBS10.5 |
10.5 |
.046" (1.2mm) |
$1.15 |
|
|
SBS11.4 |
11.4 |
.046" (1.2mm) |
$1.15 |
|
|
SBS12.4 |
12.4 |
.046" (1.2mm) |
$1.15 |
|
|
SBS13.6 |
13.6 |
.046" (1.2mm) |
$1.15 |
|
|
SBS15.0 |
15.0 |
.046" (1.2mm) |
$1.15 |
|
|
SBS16.0 |
16.0 |
.046" (1.2mm) |
$1.15 |
|
|
SBS17.0 |
17.0 |
.046" (1.2mm) |
$1.15 |
|
SBM (Square Belt Medium) belts are typically used in CD players, some cassette decks, some VCRs. I.C. (inside circumference) is shown in inches. Their thickness is .065 inches (1.65mm) - same as the thickness of a U.S. Quarter.
|
|
Part # |
I.C.* |
Thickness |
Price ea |
Purchase |
|
SBM2.3 |
2.3 |
.065" (1.65mm) |
$1.05 |
|
|
SBM2.5 |
2.5 |
.065" (1.65mm) |
$1.05 |
|
|
SBM2.8 |
2.8 |
.065" (1.65mm) |
$1.05 |
|
|
SBM3.0 |
3.0 |
.065" (1.65mm) |
$1.05 |
|
|
SBM3.12 |
3.12 |
.065" (1.65mm) |
$1.05 |
|
|
SBM3.2 |
3.2 |
.065" (1.65mm) |
$1.05 |
|
|
SBM3.4 |
3.4 |
.065" (1.65mm) |
$1.05 |
|
|
SBM3.6 |
3.6 |
.065" (1.65mm) |
$1.05 |
|
|
SBM4.0 |
4.0 |
.065" (1.65mm) |
$1.05 |
|
|
SBM4.2 |
4.2 |
.065" (1.65mm) |
$1.05 |
|
|
SBM4.5 |
4.5 |
.065" (1.65mm) |
$1.05 |
|
|
SBM4.65 |
4.65 |
.065" (1.65mm) |
$1.05 |
|
|
SBM5.0 |
5.0 |
.065" (1.65mm) |
$1.05 |
|
|
SBM5.3 |
5.3 |
.065" (1.65mm) |
$1.05 |
|
|
SBM5.6 |
5.6 |
.065" (1.65mm) |
$1.05 |
|
|
SBM6.0 |
6.0 |
.065" (1.65mm) |
$1.05 |
|
|
SBM6.5 |
6.5 |
.065" (1.65mm) |
$1.05 |
|
|
SBM7.2 |
7.2 |
.065" (1.65mm) |
$1.05 |
|
|
Part # |
I.C.* |
Thickness |
Price ea |
Purchase |
|
SBM7.5 |
7.5 |
.065" (1.65mm) |
$1.05 |
|
|
SBM8.0 |
8.0 |
.065" (1.65mm) |
$1.15 |
|
|
SBM8.5 |
8.5 |
.065" (1.65mm) |
$1.15 |
|
|
SBM8.7 |
8.7 |
.065" (1.65mm) |
$1.15 |
|
|
SBM10.0 |
10.0 |
.065" (1.65mm) |
$1.15 |
|
|
SBM11.5 |
11.5 |
.065" (1.65mm) |
$1.15 |
|
|
SBM12.5 |
12.5 |
.065" (1.65mm) |
$1.15 |
|
SBL (Square Belt Large) belts are typically used in VCRs. These are the most common sizes of square VCR belts. These belts are 2mm thick (same thickness as a U.S. Nickel). I.C. (inside circumference) is shown in inches.
|
|
Part # |
I.C.* |
Thickness |
Price ea |
Purchase |
|
SBL2.4 |
2.4 |
.075" (2.0mm) |
$1.15 |
|
|
SBL2.65 |
2.65 |
.075" (2.0mm) |
$1.15 |
|
|
SBL2.9 |
2.9 |
.075" (2.0mm) |
$1.15 |
|
|
SBL3.0 |
3.0 |
.075" (2.0mm) |
$1.15 |
|
|
SBL3.12 |
3.12 |
.075" (2.0mm) |
$1.15 |
|
|
SBL3.4 |
3.4 |
.075" (2.0mm) |
$1.15 |
|
|
SBL3.5 |
3.5 |
.075" (2.0mm) |
$1.15 |
|
|
SBL3.6 |
3.6 |
.075" (2.0mm) |
$1.15 |
|
|
SBL3.7 |
3.7 |
.075" (2.0mm) |
$1.15 |
|
|
SBL4.0 |
4.0 |
.075" (2.0mm) |
$1.15 |
|
|
SBL4.2 |
4.2 |
.075" (2.0mm) |
$1.15 |
|
|
SBL4.44 |
4.44 |
.075" (2.0mm) |
$1.15 |
|
|
SBL5.1 |
5.1 |
.075" (2.0mm) |
$1.15 |
|
|
SBL5.4 |
5.4 |
.075" (2.0mm) |
$1.15 |
|
|
SBL5.7 |
5.7 |
.075" (2.0mm) |
$1.15 |
|
|
Part # |
I.C.* |
Thickness |
Price ea |
Purchase |
|
SBL6.0 |
6.0 |
.075" (2.0mm) |
$1.15 |
|
|
SBL6.5 |
6.5 |
.075" (2.0mm) |
$1.15 |
|
|
SBL7.0 |
7.0 |
.075" (2.0mm) |
$1.15 |
|
|
SBL7.5 |
7.5 |
.075" (2.0mm) |
$1.15 |
|
|
SBL7.8 |
7.8 |
.075" (2.0mm) |
$1.15 |
|
|
SBL8.2 |
8.2 |
.075" (2.0mm) |
$1.25 |
|
|
SBL8.5 |
8.5 |
.075" (2.0mm) |
$1.25 |
|
|
SBL8.7 |
8.7 |
.075" (2.0mm) |
$1.25 |
|
|
SBL8.9 |
8.9 |
.075" (2.0mm) |
$1.25 |
|
|
SBL9.1 |
9.1 |
.075" (2.0mm) |
$1.25 |
|
|
Part # |
I.C.* |
Thickness |
Price ea |
Purchase |
|
SBL9.4 |
9.4 |
.075" (2.0mm) |
$1.25 |
|
|
SBL10.0 |
10.0 |
.075" (2.0mm) |
$1.25 |
|
|
SBL10.3 |
10.3 |
.075" (2.0mm) |
$1.25 |
|
|
SBL10.7 |
10.7 |
.075" (2.0mm) |
$1.25 |
|
|
SBL11.1 |
11.1 |
.075" (2.0mm) |
$1.25 |
|
|
SBL12.0 |
12.0 |
.075" (2.0mm) |
$1.25 |
|
|
SBL12.5 |
12.5 |
.075" (2.0mm) |
$1.25 |
|
|
SBL13.3 |
13.3 |
.075" (2.0mm) |
$1.25 |
|
|
SBL14.3 |
14.3 |
.075" (2.0mm) |
$1.25 |
|
|
SBL15.0 |
15.0 |
.075" (2.0mm) |
$1.25 |
|
SBX (Square Belt X-Large) belts are typically used in VCRs, especially older VCRs. These are the thickest square belts that we carry; these belts are 2.3mm thick (slightly thicker than a U.S. Half Dollar). I.C. (inside circumference) is shown in inches.
|
|
Part # |
I.C.* |
Thickness |
Price ea |
Purchase |
|
SBX2.5 |
2.5 |
.090" (2.3mm) |
$1.15 |
|
|
SBX3.2 |
3.2 |
.090" (2.3mm) |
$1.15 |
|
|
SBX3.7 |
3.7 |
.090" (2.3mm) |
$1.15 |
|
|
SBX4.2 |
4.2 |
.090" (2.3mm) |
$1.15 |
|
|
SBX5.7 |
5.7 |
.090" (2.3mm) |
$1.15 |
|
|
SBX6.6 |
6.6 |
.090" (2.3mm) |
$1.15 |
|
|
SBX7.5 |
7.5 |
.090" (2.3mm) |
$1.15 |
|
|
SBX8.4 |
8.4 |
.090" (2.3mm) |
$1.25 |
|
|
SBX9.1 |
9.1 |
.090" (2.3mm) |
$1.25 |
|
|
SBX10.0 |
10.0 |
.090" (2.3mm) |
$1.25 |
|
|
SBX11.6 |
11.6 |
.090" (2.3mm) |
$1.25 |
|
|
SBX12.5 |
12.5 |
.090" (2.3mm) |
$1.25 |
|
|
SBX14.3 |
14.3 |
.090" (2.3mm) |
$1.25 |
|
*I.C. is the inside circumference in inches (length of the belt if you were to cut it and lay it alongside a ruler)
Replacement Flat Belts
How to Measure Belts
|
FBS (Flat Belt Small) belts are typically used in cassette decks |
|
Part # |
I.C.* |
Thick (") |
Width (") |
Price ea |
Purchase |
|
FBS4.0 |
4.0 |
.025" |
.125-.15 |
$1.15 |
|
|
FBS5.8 |
5.8 |
.025" |
.125-.15 |
$1.15 |
|
|
FBS6.7 |
6.7 |
.025" |
.125-.15 |
$1.15 |
|
|
FBS7.0 |
7.0 |
.025" |
.125-.15 |
$1.15 |
|
|
FBS7.5 |
7.5 |
.025" |
.125-.15 |
$1.15 |
|
|
FBS8.0 |
8.0 |
.025" |
.125-.15 |
$1.25 |
|
|
FBS8.4 |
8.4 |
.025" |
.125-.15 |
$1.25 |
|
|
FBS9.0 |
9.0 |
.025" |
.125-.15 |
$1.25 |
|
|
FBS9.6 |
9.6 |
.025" |
.125-.15 |
$1.25 |
|
|
FBS9.9 |
9.9 |
.025" |
.125-.15 |
$1.25 |
|
|
FBS10.5 |
10.5 |
.025" |
.125-.15 |
$1.25 |
|
|
FBS11.0 |
11.0 |
.025" |
.125-.15 |
$1.25 |
|
|
FBS12.1 |
12.1 |
.025" |
.125-.15 |
$1.25 |
|
|
FBM (Flat Belt Medium) belts are typically used in older VCRs and 8-track players |
|
Part # |
I.C.* |
Thick (") |
Width (") |
Price ea |
Purchase |
|
FBM2.0 |
2.0 |
.025" |
.125-.15 |
$1.15 |
|
|
FBM2.7 |
2.7 |
.025" |
.125-.15 |
$1.15 |
|
|
FBM3.6 |
3.6 |
.025" |
.18-.235 |
$1.15 |
|
|
FBM7.5 |
7.5 |
.025" |
.18-.235 |
$1.25 |
|
|
FBM7.8 |
7.8 |
.025" |
.18-.235 |
$1.25 |
|
|
FBM8.6 |
8.6 |
.025" |
.18-.235 |
$1.25 |
|
|
FBM9.0 |
9.0 |
.025" |
.18-.235 |
$1.25 |
|
|
FBM9.6 |
9.6 |
.025" |
.18-.235 |
$1.25 |
|
|
FBM9.9 |
9.9 |
.025" |
.18-.235 |
$1.25 |
|
|
FBM10.2 |
10.2 |
.025" |
.18-.235 |
$1.25 |
|
|
Part # |
I.C.* |
Thick (") |
Width (") |
Price ea |
Purchase |
|
FBM10.5 |
10.5 |
.025" |
.18-.235 |
$1.40 |
| |
