Fender™ Knobs

We carry a complete selection of Fender™ Amplifier parts for both vintage and modern amps.

Back to Fender™ Parts Index



Click on photo for
larger view
KNOB, Fender™ STYLE, SET-SCREW
Fender™ style amp knob, skirted with 1-10 numbering.  Traditional "Witches Hat" design.   For vintage Fender™ amps in the original blackface and silverface series, as well as the blackface and silverface reissue series.  With set-screw, for 1/4" smooth shaft pots.  Replaces Fender™ part number 0990930000.
Part #FVSK
$5.50


Click on photo for
larger view
KNOB, Music Man™, SET-SCREW
Music Man™ style amp knob, skirted with 1-10 numbering.  Traditional "Witches Hat" design.   For vintage Music Man™ amps.  With set-screw, for 1/4" smooth shaft pots.  These are different than the Fender skirted knobs.   A lot of people put Fender knobs on Music Man amps, but they won't exactly match the other knobs.   This is the exact replacement for Music Man.
Part #K-155
$5.50


Click on photo for
larger view
KNOB KIT, Fender™, Black with Pointer with bushing.   Replacement for Fender™ Blues Junior III.  Upgrade knob for original Blues Junior, Bronco, and Pro Junior.  Includes the Fender™ style 36620000 Black Chicken-Head knob and the 0033206049 bushing.  Knob is a 1/4" set-screw type.  This combination replaces the original 041710 push-on knob used on the original Blues Junior, Bronco and Pro Junior - the 041710 knob is now discontinued.
Part #K-710
$2.95


Click on photo for
larger view
MULTI-PACK, KNOB, CHICKEN HEAD, SET  SCREW, BLACK, SET OF 6 - SAVE!
Used in Fender™ and many other retro style amps.  Black.   Fits 1/4" shaft, brass insert, with set screw.   Set of 6 knobs.
Part #CHKBK-6
$7.49


Click on photo for
larger view
KNOB, CHICKEN HEAD, SET  SCREW, BLACK
Used in Fender™ and many other retro style amps.  Black.   Fits 1/4" shaft, brass insert, with set screw.
Part #CHKBK
$1.95


Click on photo for
larger view
KNOB, CHICKEN HEAD, HEX SET  SCREW, BLACK, PROFESSIONAL QUALITY
Used in Fender™ and many other retro style amps.  Black, with black hex set-screw.  Fits 1/4" shaft, brass insert.   Standard chicken-head knob size, 31.5mm nose to tail, 13.5mm tall.  A professional quality knob - very well made.  Need a hex key to use with this knob's hex set-screw?   Click here.
Part #BHKCHK
$1.99

We only have 2 of this knob left!




Click on photo for
larger view
KNOB, CHICKEN HEAD, SET  SCREW, WHITE
Used in Fender™ and many other retro style amps.  White.   Fits 1/4" shaft, brass insert, with set screw.
Part #CHKWH
$1.95


Click on photo for
larger view

KNOB, CHICKEN HEAD, SET  SCREW, BLUE
Used in Fender™ and many other retro style amps.  Blue.   Fits 1/4" shaft, brass insert, with set screw.
Part #CHKBL
$1.95


Click on photo for
larger view
KNOB, CHICKEN HEAD, SET  SCREW, CREAM
Used in Fender™ and many other retro style amps.  Cream.   Fits 1/4" shaft, brass insert, with set screw.
Part #CHKCR
$1.95


Click on photo for
larger view
KNOB, CHICKEN HEAD, SET  SCREW, RED
Used in Fender™ and many other retro style amps.  Red.   Fits 1/4" shaft, brass insert, with set screw.
Part #CHKRD
$1.95



Click on photo for
larger view
KNOB, Fender™, 1-10, Acoustasonic series,
Brown.
Genuine Fender™ amp knob, skirted with 1-10 numbering.   Brown in color, center is indented chrome.  For the Acoustasonic series of amplifiers.   Used on Acoustasonic amps manufactured from 2005-2011.   Knob is a slip-on, designed to fit a "D-shaped" shaft.   Original Fender™ part number 0055758049.
Part #K-758
$8.50

Click on photo for
larger view
KNOB, Fender™, 1-10, Acoustasonic series,
Brown.
Genuine Fender™ amp knob, skirted with 1-10 numbering.   Brown in color.  For the Acoustasonic series of amplifiers.   Used on Acoustasonic amps manufactured from 1998-2004.   Knob is a slip-on, designed to fit a "D-shaped" shaft.   Original Fender™ part number 00551018000.
Part #K-329
$8.50

Click on photo for
larger view
KNOB, Fender™, 1-10, Princeton 65 and Princeton 65 DSP
Genuine Fender™ amp knob, black, chrome center disc, skirted with 1-10 numbering.  Knob is a slip-on, designed to fit a "D-shaped" shaft (with flat portion of "D" shaft facing the 1 o'clock position when potentiometer is turned down to minimal level)7/8" diameter.  For the Princeton 65/65 DSP/650, Champion 30/30 DSP,  Super Champ X2, Super Champ XD, Cyber-Champ, Super Bassman (2012) amplifiers.  Also used as the line-out level control knob on the Acoustasonic Jr DSP.    Original Fender™ part number 0054419000.
Part #K-328
$3.95


Click on photo for
larger view
KNOB, Fender™ style "mini witch's hat", skirted 1-10   Fender™ style amp knob, black, chrome center disc, skirted, with 1-10 numbering.  Knob is a slip-on, designed to fit a knurled shaft pot. Base is 7/8" diameter.   Fits any split knurled shaft pot, such as those found on certain models of the Sidekick series, the Rumble series etc.   Same as K-328, but for knurled shaft pots instead of D-shaft.  Also will fit other amp brands with knurled shaft pots.
Part #K-338
$1.95


Click on photo for
larger view
BUSHING, Fender™, for push-on knobs such as the K-2049 and K-3049 and others.  This bushing slides over the pot shaft before the knob is installed, and stabilizes the shaft as well as keeping the knob from rubbing the front faceplate.  The tapered end of the bushing fits into the hole in the faceplate.  The knob is inserted after the bushing is in place, and hides the bushing from view.  Original Fender™ part number 0033206049.
Part #K-6049
$1.00


Click on photo for
larger view
BUTTON, for push switch, Black.  This black button pushes onto the switch stem.   Used on channel control and drive boost switches on the front panel of the Fender™ Hot Rod Deluxe, Hot Rod Deville, Blues Deluxe, Blues Deville, Blues Junior. Original Fender™ part number 0028104000.   Button only - not the complete switch.   For the switch, see SW-028.   Fits switches with actuator shaft of 2.7mm square.
Part #K-058
$2.95


Click on photo for
larger view
BUTTON, for push switch, White.  This white button pushes onto the switch stem.   Used on channel control and drive boost switches on the front panel of the Fender™ Hot Rod Deluxe III, Hot Rod Deville III, and on the FAT switch of the Blues Junior III and Blues Junior IV.  Used on the channel selection switch of the Super champ X2 and Super Champ XD. Original Fender™ part number 0048451000.   Button only - not the complete switch.   For the switch, see SW-028.   Fits switches with actuator shaft of 2.7mm square.
Part #K-048
$2.95


Click on photo for
larger view
KNOB, Fender™, Red with Pointer
The infamous Fender Red Knob.  Genuine Fender™ amp knob, red with white pointer.   Knob is a slip-on, designed to fit a "D-shaped" shaft.  Original Fender™ part number 0990931000 and 025952.  Will NOT fit certain models of amps, including the M-80 heads and rack-mount models and the BXR-300R and BXR-300C.
Part #K-320
Discontinued by Fender.   No longer available.

Click on photo for
larger view
KNOB, Fender™, Black with Pointer
Genuine Fender™ amp knob, black with white pointer.   Knob is a slip-on, designed to fit a "D-shaped" shaft.  Original Fender™ part number 0990932000.  Will NOT fit certain models of amps, including the M-80 series and BXR series.   Will not fit combo amps which have pots with black plastic shafts, such as the Princeton 112 and Princeton 112 Plus.
Part #K-321
Discontinued by Fender.   No longer available.

Click on photo for
larger view
KNOB, Fender™ Style, Vintage Cream
Replaces Fender™ part number 0990933000.  "Fender™ Barrel" knob, cream white with brass inset and set-screw as used by:  Fender™ 1960-­1964 for the Fender™ Bassman, Showman and Bandmaster Amp, and for several Fender™ Custom Shop and Fender™ Reissue amps:  Tone Master, Custom Vibrolux Reverb, Vibroking, Super Sonic Amp (blonde) etc.
Part #K-315
$2.95


Click on photo for
larger view
KNOB, Fender™ Style, Vintage Cream, Set of 6
Replaces Fender™ part number 0990933000.  "Fender™ Barrel" knob, cream white with brass inset and set-screw as used by:
Fender™ 1960-1964 for the Fender™ Bassman, Showman and Bandmaster Amp, and for several Fender™ Custom Shop and Fender™ Reissue amps:  Tone Master, Custom Vibrolux Reverb, Vibroking, Super Sonic Amp (blonde) etc.  Set of 6 knobs.

Part #K-315-6
$16.95
(for pack of 6 knobs)



Click on photo for
larger view
KNOB, Fender™ Style, Vintage Brown
Fender™ style amp knob, brown color with white pointer.   Used on Fender™ "Brownface" series amps from 1961 through 1963.   Knob is secured by set-screw, designed to fit a 1/4" shaft.  Includes internal brass inset.  Replaces Fender™ part number 0990934000, these knobs were used by Fender™ in the early 1960s for the Brown-Tolex Amps (Princeton 6G2, Deluxe 6G3, Super 6G4, Pro 6G5, Tremolux 6G9, Vibrolux 6G11, Concert 6G12, Reverb Unit 6G15, Vibroverb 6G16), and others Also very similar to the knob used on the Mesa-Boogie Maverick Dual Rectifier model - Mesa Boogie part number 408020.
Part #K-316
$2.95


Click on photo for
larger view
KNOB, Fender™ Style, Vintage Brown, Set of 6
Fender™ style amp knob, brown color with white pointer.   Used on Fender™ "Brownface" series amps from 1961 through 1963.   Knob is secured by set-screw, designed to fit a 1/4" shaft.  Includes internal brass inset.  Replaces Fender™ part number 0990934000, these knobs were used by Fender™ in the early 1960s for the Brown-Tolex Amps (Princeton 6G2, Deluxe 6G3, Super 6G4, Pro 6G5, Tremolux 6G9, Vibrolux 6G11, Concert 6G12, Reverb Unit 6G15, Vibroverb 6G16), and others Also very similar to the knob used on the Mesa-Boogie Maverick Dual Rectifier model - Mesa Boogie part number 408020.  Set of 6 knobs.
Part #K-316-6
$16.95
(for pack of 6 knobs)


Click on photo for
larger view
KNOB, Fender™ Style, Vintage Black
Fender™ style amp knob, black color with white pointer.  Includes internal brassinset.   Knob is secured by set-screw, designed to fit a 1/4" shaft.   Can be used for Fender™ Brown-Tolex Amps (Princeton 6G2, Deluxe 6G3, Super 6G4, Pro 6G5, Tremolux 6G9, Vibrolux 6G11, Concert 6G12, Reverb Unit 6G15, Vibroverb 6G16)
Part #K-325
$2.95
