Jacks

British Style     Jalco/Kobiconn Style

Switchcraft Open-Frame Style    Switchcraft Enclosed Jacks    Miscellaneous Types

Jack Nuts and Washers


Jacks
  Switchcraft

Click on photo for
larger view
JACK, 1/4", MONO, OPEN CIRCUIT, WIRED, Switchcraft
Found in many guitars, effects pedals, amps speaker output.  Includes nut and washer.
Part #J-11
$4.29


Click on photo for
larger view
JACK, 1/4", MONO, OPEN CIRCUIT, WIRED, Switchcraft, LONG BUSHING
Same as the J-11 jack, but with longer (3/8") threaded bushing for mounting in thicker panels.  Includes nut and washer.
Part #J-L11
$5.39


Click on photo for
larger view
JACK, 1/4", MONO, OPEN CIRCUIT, WIRED, Switchcraft, LONG BUSHING, ISOLATION WASHERS
Same as the Switchcraft L11 but includes fiber isolation washers. The isolation washers keep the jack from making contact with your chassis. This leaves the jack ungrounded which is needed in certain applications.

Part #J-L11W
$5.79


Click on photo for
larger view
JACK, 1/4", MONO, CLOSED CIRCUIT (SHORTING), WIRED, Switchcraft
Found in vintage Fender
(and other) amps as the input jack.   Also used in the Hot Rod Deluxe/Deville, Blues Deluxe/Deville as the main speaker out jack.  Includes nut and washer.    Fender™ part number 0021550000 (originally 021550).   Peavey part number 71466004.
Part #J-12A
$4.79


Click on photo for
larger view
JACK, 1/4", MONO, CLOSED CIRCUIT (SHORTING), WIRED, Switchcraft, LONG BUSHING
Same as the J-12A jack, but with longer (3/8") threaded bushing for mounting in thicker panels.  Includes nut and washer.
Part #J-L12A
$5.50


Click on photo for
larger view
JACK, 1/4", MONO, TIP SHUNT, WIRED, Switchcraft, LONG BUSHING, ISOLATION WASHERS
Same as the Switchcraft L12A jack but includes a set of isolation washers. The isolation washers keep the jack from making contact with your chassis. This leaves the jack ungrounded which is needed in certain applications.   Commonly used in older Fender™ Hot Rod Deluxe/Deville and Blues Deluxe/Deville amps to replace the fragile input jacks.
Part #J-L12AW
$5.99


Click on photo for
larger view
JACK, 1/4", TIP-RING-SLEEVE, OPEN CIRCUIT, WIRED, Switchcraft
Used with T/R/S plugs for either balanced connections or stereo connections.   Also very common in guitars with active pickups, and as the input jack on some effects pedals.   The ring conductor is used in these cases to "turn on" the battery by tying one leg of the battery to ground via the plug.  Fender part number 0013043000.
Part #J-12B
$4.35


Click on photo for
larger view
JACK, 1/4", TIP-RING-SLEEVE, OPEN CIRCUIT, WIRED, Switchcraft, LONG BUSHING
Same as the J-12B jack, but with longer (3/8") threaded bushing for mounting in thicker panels.  Includes nut and washer.
Part #J-L12B
$5.99


Click on photo for
larger view
JACK, 1/4", TIP-SLEEVE, WITH ISOLATED SWITCHING.  Switchcraft
Used with for special switching applications - the two conductors for the switch are completely isolated from both the "hot" audio signal and the ground connection.   Used in some vintage amplifiers, including some early Fender™ models.   Isolated switch is normally open - closes when a plug is inserted.
Part #J-13
$10.50


Click on photo for
larger view
JACK, 1/4", TIP-SLEEVE, WITH ISOLATED SWITCHING.  Switchcraft
Used with for special switching applications - the two conductors for the switch are completely isolated from both the "hot" audio signal and the ground connection.   Used in some vintage amplifiers, including some early KUSTOM™ models including the KUSTOM™ 150.  KUSTOM™ part number 030-1006-00.   Used in some Sunn models, such as the Concert Lead and Concert Bass. Also used in some Rivera-era Fender models, including the Champ II, original Super Champ, 300PS, Super Twin, and Fender 75. Fender part number 011028. Isolated switch is normally closed - opens when a plug is inserted.
Part #J-13E
$13.95


Click on photo for
larger view
JACK, 1/4", TIP-SLEEVE, WITH TRANSFER SWITCHING.  Switchcraft 13A Jack.
Used with for special switching applications - the tip contacts one terminal when no plug is inserted, and contacts a different terminal with the plug in place.   Used in
a number of Fender™ models, both vintage and modern as the extension speaker jack (ex: Blues and Hot Rod Deluxe and Deville models).  Original Fender™ part number 0041701000 (originally 042701).   Also found in some Peavey amps, such as the Classic 50 speaker jack.
Part #J-13A
$10.95


Click on photo for
larger view
JACK, 1/4", TIP/RING/SLEEVE, WITH TIP SHUNT.  Switchcraft 13B Jack.
Tip/Ring/Sleeve Switchcraft jack.   Tip has a shunt contact, ring contact is open circuit.

Part #J-13B
$9.95


Click on photo for
larger view.   Jack is in the picture to demonstrate how the washers are installed - jack is NOT included with the washers.
INSULATING SHOULDER WASHER, FIBER
Pair of fiber insulating shoulder washers for Switchcraft jacks with metal bushings.   Used to mount standard jacks in a 1/2" diameter chassis hole, while insulating the metal bushing (ground) of the jack from the chassis.   ID 3/8", OD 1/2".  Works great when replacing isolated plastic jacks with a more durable metal jack, which is frequently done on the input jacks of the Fender™ Hot Rod Deville/Deluxe and Blues Deville/Deluxe.   Two washers are used on each jack, and the "shoulders" are placed facing each other through the chassis.   The washers not only isolate the ground of the jack electrically for noise reduction, but also stabilize the jack in the 1/2" diameter hole.   Jack shown in picture NOT included.   Works well with the Switchcraft J-11, J-L11, J-12A, J-L12A, J-12B, J-L12B, J-13, J-13A, J-112APC, J-112BX, J-114BX, J-521 and J-524 jacks.
Part #ISW-3069
$0.49
(For a pair of washers.  Each jack needs two washers.)



Click on photo for
larger view
JACK, 1/4", MONO, CLOSED CIRCUIT MONO, PC MOUNT, Switchcraft STYLE, NON-ISOLATED
Common PC mount input jack.   3 pins, mono, tip shunt. Shield tied to chassis mount.   Used in many amplifiers.   Fender™ part number 030771.   Nut and washer included.

Part #J-112APC
$5.95


Click on photo for
larger view
JACK, 1/4", MONO, OPEN CIRCUIT STEREO, PC MOUNT, Switchcraft STYLE, NON-ISOLATED METAL THREADS.
Common PC mount input jack.   3 pins, stereo, tip/ring/sleeve, no switching.  Shield tied to metal threads.   Used in many pedals and acoustic guitars.    Nut and washer included.

Part #J-112BPC
$5.95


Click on photo for
larger view
JACK, 1/4", MONO, CLOSED CIRCUIT MONO, PC MOUNT, Switchcraft STYLE, ISOLATED NYLON BUSHING
Found in many applications.  3 pins, mono, tip shunt.   Isolated sleeve.   Nut and washer included.

Part #J-N112APC
$6.95


Click on photo for
larger view
JACK, 1/4",  CLOSED CIRCUIT STEREO, PC BOARD MOUNTING, Switchcraft, METAL BUSHING
Tip is switched  (normally closed), ring conductor is not switched.  4 pins for inserting into PC board, metal bushing.  Nut and washer included.  Genuine Switchcraft

Part #J-113B-PC

This is a custom Switchcraftjack, and is not returnable.  Be sure this is the correct jack before placing an order.  If you have questions, we are here to help.    Contact Us.

$6.95


Click on photo for
larger view
JACK, 1/4",  CLOSED CIRCUIT STEREO, PC BOARD MOUNTING, Switchcraft, METAL BUSHING
Tip is open, ring is switched  (normally closed).  4 pins for inserting into PC board, metal bushing.  Unusual arrangement used in special applications.   Nut and washer included.  Genuine Switchcraft

Part #J-113F-PC

This is a custom Switchcraftjack, and is not returnable.  Be sure this is the correct jack before placing an order.  If you have questions, we are here to help.    Contact Us.

$6.95


Click on photo for
larger view
JACK, 1/4",  OPEN CIRCUIT STEREO, HAND WIRED, Switchcraft STYLE, NON-ISOLATED METAL BUSHING
Common input jack in guitars, hand-wired effects pedals.  3 pins T/R/S, open circuit, non-switched.  Nut and washer included.

Part #J-112BX
$4.50


Click on photo for
larger view
JACK, 1/4",  OPEN CIRCUIT MONO, HAND WIRED, Switchcraft STYLE, NON-ISOLATED METAL BUSHING
Common input jack in guitars, hand-wired effects pedals.  2 pins T/S, open circuit, non-switched.  Nut and washer included.

Part #J-111X
$4.39



Click on photo for
larger view
JACK, 1/4",  OPEN CIRCUIT MONO, SOLDER LUGS, Switchcraft STYLE, ISOLATED NYLON BUSHING
Common input jack in guitars, hand-wired effects pedals, footswitch jacks.  2 lugs
(tip and sleeve), open circuit, non-switched, nylon bushing for ground isolation.  Nut and washer included.

Part #J-N111X
$3.99



Click on photo for
larger view
JACK, 1/4", MONO, CLOSED CIRCUIT MONO, SOLDER LUGS, Switchcraft STYLE, ISOLATED NYLON BUSHING
3 lugs, mono, tip shunt.  Nylon bushing for ground isolation.  Used in many amplifiers.  Nut and washer included.

Part #J-N112AX
$6.69



Click on photo for
larger view
JACK, 1/4",  OPEN CIRCUIT STEREO, HAND WIRED, Switchcraft STYLE, ISOLATED NYLON BUSHING
Common input jack in guitars, hand-wired effects pedals.  3 pins T/R/S, open circuit, non-switched, nylon bushing for isolation.  Nut and washer included.

Part #J-N112BX
$4.50


Click on photo for
larger view
JACK, 1/4",  CLOSED CIRCUIT STEREO, PC BOARD MOUNTING, Switchcraft, INSULATED BUSHING
Tip is switched  (normally closed), ring conductor is not switched.  4 pins for inserting into PC board, insulated bushing.  Nut and washer included.  Genuine Switchcraft

Part #J-N113B-PC

This is a custom Switchcraftjack, and is not returnable.  Be sure this is the correct jack before placing an order.  If you have questions, we are here to help.    Contact Us.

$6.95



Click on photo for
larger view
JACK, 1/4",  CLOSED CIRCUIT MONO, HAND WIRED, Switchcraft STYLE, METAL BUSHING
Common input jack in guitar amps.  T/S closed circuit, switched, metal bushing, 3 pins for wiring.  Nut and washer included.  Fender part number 0066439000.   Found in a number of SWR amps as the input jack.

Part #J-112AX
$4.50



Click on photo for
larger view
JACK, 1/4",  CLOSED CIRCUIT STEREO, HAND WIRED, Switchcraft STYLE, METAL BUSHING
Common input jack in guitars, hand-wired effects pedals.  T/R/S closed circuit, switched, metal bushing, 5 pins for wiring.  Nut and washer included.  Genuine Switchcraft

Part #J-114BX
$6.95



Click on photo for
larger view
JACK, 1/4",  CLOSED CIRCUIT STEREO, HAND WIRED, Switchcraft, NYLON BUSHING

T/R/S closed circuit, switched, nylon bushing for ground isolation from enclosure, 5 pins for wiring.  Nut and washer included.  Genuine Switchcraft

Part #J-N114BX
$6.95



Click on photo for
larger view
JACK, 1/4",  CLOSED CIRCUIT STEREO, HAND WIRED, Switchcraft STYLE, METAL BUSHING
Tip is switched  (normally closed), ring conductor is not switched.  4 pins for wiring, metal bushing. Used in DOD™ and other brands.   Nut and washer included.  Genuine Switchcraft

Part #J-113BX

This is a custom Switchcraftjack, and is not returnable.  Be sure this is the correct jack before placing an order.  If you have questions, we are here to help.    Contact Us.

$6.95



Click on photo for
larger view
JACK, 1/4",  CLOSED CIRCUIT STEREO, HAND WIRED, Switchcraft STYLE, METAL BUSHING
Tip is open, ring is switched  (normally closed).  4 pins for wiring, metal bushing.  Unusual arrangement used in special applications.   Nut and washer included.  Genuine Switchcraft

Part #J-113FX

This is a custom Switchcraftjack, and is not returnable.  Be sure this is the correct jack before placing an order.  If you have questions, we are here to help.    Contact Us.

$6.95


Click on photo for
larger view
JACK, 1/4", MONO, OPEN CIRCUIT, WIRED, AUTHENTIC Lumberg
German craftsmanship in a compact 1/4" jack.   Mono, open circuit.  Features the most compact size for a 1/4" jack available.   Perfect for tight fits in pedals.    Download datasheet
Part #J-303
$3.89


Click on photo for
larger view
JACK, 1/4", STEREO, OPEN CIRCUIT, WIRED, AUTHENTIC Lumberg
German craftsmanship in a compact 1/4" jack.   Stereo, open circuit.  Features the most compact size for a 1/4" jack available.  Perfect for tight fits in pedals.  Commonly used as the input jack in many pedals.  Download datasheet
Part #J-304
$3.99



Click on photo for
larger view
JACK, 1/4",  OPEN CIRCUIT STEREO, PC MOUNT, Switchcraft STYLE, ISOLATED NYLON BUSHING
Common PC mount input jack.  3 pins stereo, open circuit, non-switched.  Nylon bushing ; shield is not tied to chassis mount.   Nut and washer included.

Part #J-N112BPC
$3.99


Click on photo for
larger view
JACK, 1/4", MONO, CLOSED CIRCUIT, RIGHT ANGLE PC MOUNT, Switchcraft STYLE, NYLON THREADS, 2 PINS
Common input jack in Crate
& Ampeg, and in some solid state products from Fender during the early 1980s. 2 PC board pins.  Nut and washer included.


Part #RN111PC
$6.95


Click on photo for
larger view
JACK, 1/4", MONO, CLOSED CIRCUIT, RIGHT ANGLE PC MOUNT, Switchcraft STYLE, NYLON THREADS, 3 PINS
Common input jack in Crate
& Ampeg, and in some solid state products from Fender during the early 1980s.   Nut and washer included.   Fender part number 018594.


Part #RN112APC
$6.95


Click on photo for
larger view
JACK, 1/4", MONO, OPEN CIRCUIT, RIGHT ANGLE PC MOUNT, Switchcraft STYLE, NYLON THREADS, 3 PINS (TIP/RING/SLEEVE)
Found in a number of products in the 80s and 90s, including mixing consoles, effects pedals, etc.  Open circuit (no switching) tip/ring/sleeve.  3 PC board pins.   Nut and washer included.


Part #RN112BPC
$6.95



Click on photo for
larger view

JACK, 1/4", Peavey™ ORIGINAL, DUAL TIP HID, PC MOUNT, MONO, 4 PINS (WIDE PINS).  SPECIAL APPLICATION!!
This jack is for use in Peavey™ products only, and is unusual in that two different pins contact the tip of the plug.  One of the tip contacts is switched (normally closed), and the other tip contact is open.  The pins on this jack are wide (1.7mm), so the hole in the PC board must be large enough to accept the pin.   For the same jack with narrow pins, see the J-214.   This jack is exclusive to Peavey™.  Peavey part number 71466032 or 31466032.  Used for a variety of functions on Peavey products, including input jacks.  Nut and washer included.
Part #J-521
$6.95



Click on photo for
larger view

JACK, 1/4", Peavey™ ORIGINAL, DUAL TIP HID, PC MOUNT, MONO, 4 PINS (NARROW PINS).  SPECIAL APPLICATION!!
This jack is for use in Peavey™ products only, and is unusual in that two different pins contact the tip of the plug.  One of the tip contacts is switched (normally closed), and the other tip contact is open.  The pins on this jack are narrow (1.1mm).  For the same jack with wide pins, see the J-521.  This jack is exclusive to Peavey™.  Peavey part number 71466214 or 31466214. Used for a variety of functions on Peavey products, including input jacks. Nut and washer included. Found in the Classic 20, Classic 30, Delta Blues, 112TI, 115TI, and some Ecoustic models, among others.
Part #J-214
$5.95



Click on photo for
larger view

JACK, 1/4", Peavey™ ORIGINAL, DUAL TIP HID, PC MOUNT, MONO, 4 PINS, INSULATED.   SPECIAL APPLICATION!!
This jack is for special applications in Peavey™ products only, and is unusual in that two different pins contact the tip of the plug.  One of the tip contacts is switched (normally closed), and the other tip contact is open.  This jack is exclusive to Peavey™.   Same as J-521 except that the threads are insulated.  Nut and washer included.

Part #J-522
$5.95


Click on photo for
larger view
JACK, 1/4", PC MOUNT, STEREO, 5 PINS, SWITCHED, INSULATED.   Both tip and ring are switched (normally closed).   Used in Peavey™ and other brands.  Same as J-114BPC, except that the threads are insulated.  Nut and washer included.   This version has standard wide pins for insertion into PC board.   See the J-527 for narrow pins for small PC board holes.

Part #J-523
$6.95



Click on photo for
larger view
JACK, 1/4", PC MOUNT, STEREO, 5 PINS, SWITCHED, INSULATED.   Both tip and ring are switched (normally closed).   Used in Peavey™ and other brands.  Same as J-523, except that the pins are narrow for insertion into smaller PC holes.  Nut and washer included.

Part #J-527
$6.95


Click on photo for
larger view
JACK, 1/4", PC MOUNT, STEREO, 5 PINS, SWITCHED, METAL BUSHING.
Both tip and ring conductors are switched (normally closed).  5 pins.    Original Peavey
part number 31466217.   Found in most Peavey Vyper models as the input jack.  Used in Peavey, Mackie and many other brands.  Replaces Switchcraft 114BPCX and 114BPCSX.  Nut and washer included.

Part #J-217
$4.95


Click on photo for
larger view
JACK, 1/4", PC MOUNT, STEREO, 5 PINS, SWITCHED, INSULATED.   Both tip and ring are switched (normally closed).   Used in Peavey™ and other brands.  Same as J-114BPC, except that the threads are insulated.  Nut and washer included.   This version has standard wide pins for insertion into PC board.   See the J-527 for narrow pins for small PC board holes.

Part #J-523
$6.95


Click on photo for
larger view
ECONOMY JACK, 1/4", PC MOUNT, STEREO, 5 PINS, SWITCHED, METAL BUSHING.
Both tip and ring conductors are switched (normally closed).  5 pins.     Used in Peavey™, Mesa/Boogie, Mackie and many other brands.  Replaces Switchcraft 114BPCX and 114BPCSX.  Nut and washer included.

Part #J-529
$2.99


Click on photo for
larger view
JACK, 1/4", STEREO, CLOSED CIRCUIT, PC BOARD MOUNTING, Switchcraft, METAL BUSHING
Common PC mount jack in guitar amps, mixers, etc.   5 pins for inserting into PC board, stereo, tip and ring shunt. Shield tied to chassis mount.   Often used for headphone jacks, insert jacks, FX loop jacks, etc.   Nut and washer included.   Genuine Switchcraft.

Part #J-114B-PC
$6.95


Click on photo for
larger view
SAVE WITH MULTIPACK!  JNUT-38 JACK NUT AND WASHER, METAL, SWITCHCRAFT, SET OF 6
Genuine Switchcraft™ nut and washer set for the blackface/silverface Fender™ bias pot, Mesa Boogie pots, and the CTS or Alpha pots with 3/8" bushing (found on original vintage Fender™ blackface and silverface), as well as Peavey™ and Switchcraft™ 1/4" jacks.  Does NOT fit the 24mm Marshall™ pots.   Set of 6 washers and 6 nuts.
Part #JNUT-38-6
$4.50
(Set of 6 washers and 6 nuts)



Click on photo for
larger view
JACK NUT AND WASHER, METAL, SWITCHCRAFT
Genuine Switchcraft™ nut and washer set for the blackface/silverface Fender™ bias pot, Mesa Boogie pots, and the CTS or Alpha pots with 3/8" bushing (found on original vintage Fender™ blackface and silverface), as well as Peavey™ and Switchcraft™ 1/4" jacks.  Does NOT fit the 24mm Marshall™ pots.
Part #JNUT-38
$0.89
(Set of 1 washer and 1 nut)


  Jalco/Kobiconn



Click on photo for
larger view

JACK, 1/4", TIP/SLEEVE 4 PIN, PC MOUNT.   Mono, 4 pin. Fits certain Fender™, Hartke™ and Vox™ amp models 1988 - present.  Nut and washer are included.  Replacement nut/washer set is the JN-916.


Part # J-506
$2.89



Click on photo for
larger view

SAVE WITH MULTIPACK!  JACK, 1/4", TIP/SLEEVE 4 PIN, PC MOUNT, Fender STYLE  1988 - Present.   PACK OF 6 JACKS.
Fender
Style PC mount 1/4" jack. Mono, 4 pin. Fits certain Fender amp models 1988 - present.  Also commonly found on Hartke™ amps.    Fender™ part numbers 0990912000, 0037036000, 990912, and 037036.   Pack of 6 Jacks, including nuts and washers.  Replacement nut/washer is the JN-916.

Part # J-506-6
$15.95
(For 6 Jacks)



Click on photo for
larger view

JACK, 1/4", TIP/SLEEVE 5 PIN, PC MOUNT, Epiphone/Gibson AMPS
PC mount 1/4" jack. Mono, 5 pin. Used in some Epiphone/Gibson
amps, some ADA Processors, as well as some other brands.  Nut and washer included.  Replacement nut/washer set is the JN-916.


Part # J-506A
$5.55



Click on photo for
larger view

JACK, 1/4", TIP/SLEEVE 3 PIN, PC MOUNT, Used in Fender Squire and Sidekick Amps from the Rivera-era (80s, early 90s)
PC mount 1/4" jack. Mono, 3 pin.   Also used in some Fender
Squire amps, such as the Champ 12 Champ 15, 15G and Sidekick 15 and 15B.   Not used in the BXR300C or BXR300R.  Used in the Marshall MS-2 Mini Amp.  Nut and washer are included.

Part # J-506B
$5.95



Click on photo for
larger view

JACK, 1/4", TIP/SLEEVE 3 PIN, PC MOUNT, Used in Fender BXR-300C and BXR-300R from the Rivera-era (80s, early 90s)
PC mount 1/4" jack. Mono, 3 pin.  Note unusual pin arrangement - different from the 3-pin J-506B.   Replaces Fender part number 025929.  Nut and washer are included.

Part # J-506BXR
$5.95



Click on photo for
larger view

JACK, 1/4", TIP/SLEEVE 5 PIN, PC MOUNT, Used in Danelectro models from the late 1990s.

PC mount 1/4" jack. Mono, 5 pin.    Replacement nut/washer set is the JN-916.   Found in the Danelectro Dirty Thirty, Nifty Fifty and Nifty Seventy.  Nut and washer are included.  Replacement nut/washer set is the JN-916.

Part # J-506C
$5.70



Click on photo for
larger view

SAVE WITH ASSORTMENT MULTIPACK!  THIS PACK CONTAINS THREE J-506 (4 PIN) AND THREE J-507 (9-PIN) JACKS.
Many amps contain both the 4 pin and the 9 pin jacks.   This assortment gives you 3 of each jack ...  Three J-506, and three J-507.    Replaces Fender™ part numbers 0990912000, 0037036000, 990912, 037036,  and 0990913000, 025931, 990913.  Pack of 6 Jacks, including nuts and washers

Part # J-5067-6
$14.99
(For 3 J-506 Jacks
and 3 J-507 Jacks)




Click on photo for
larger view

JACK, 1/4", TIP/RING/SLEEVE, 9 PIN, PC MOUNT, Fender STYLE 1988 - Present.
Fender
PCB mount 1/4" jack.  Stereo, 9 pin. Fits certain Fender amp models 1988 - present.   Used as the input jack on the Ultimate Chorus, Princeton Chorus, and similar solid-state models from the 1990's.  Replaces Fender™ part numbers 031570, 031570000, 0990913000, 025931, 990913, and 0025931000.   Also used by other amp manufacturers.   Click here for specifications.  Includes nut and washer. Replacement nut/washer set is the JN-916.

Part # J-507
$3.05



Click on photo for
larger view

SAVE WITH MULTIPACK!  JACK, 1/4", TIP/SLEEVE 9 PIN, PC MOUNT, Fender STYLE  1988 - Present.   PACK OF 6 JACKS.
Fender
style PC mount 1/4" jack. Stereo, 9 pin. Fits certain Fender amp models 1988 - present.  Also commonly found on Hartke amps.   Used as the input jack on the Ultimate Chorus, Princeton Chorus, and similar solid-state models from the 1990s.  Replaces Fender™ part numbers 0990913000, 025931, 990913, and 0025931000.  Nuts and washers included.  Click here for specifications.   Pack of 6 Jacks.

Part # J-507-6
$16.95
(For 6 Jacks)


Click on photo for
larger view
JACK, 1/4", Used in Fender, PCB, MONO CLOSED CIRCUIT
PCB mono closed circuit.   Original Fender™ part number 0037117000.    Nut and washer are included.
Part #J-512
$8.50



Click on photo for
larger view

JACK, 1/4", TIP/RING/SLEEVE, 7 PIN, PC MOUNT, Fender, Hartke, B-52, Randall, and Crate Amps.  Fender™, Hartke™, Randall™, B-52™ or Crate™ PCB mount 1/4" jack.  7 pins.   Fits several Hartke amp models 1990 - present, and several Crate models, especially in the GX series.  Used in the Fender SKX65R and SKX100R for the input jacks.  Used in some Fender Squier and Sidekick amps as the headphone jack.   Replaces Hartke part number 350023 and 300519.  Replaces Fender part number 022923.  Includes nut and washer.  Replacement nut/washer set is the JN-916.

Part # J-545
$6.70


Click on photo for
larger view

JACK, 1/4", TIP/RING/SLEEVE, 6 PIN, PC MOUNT, ADA MP-1 Input Jack.  Hard-to-find 6-pin input jack used in SOME VERSIONS of the ADA MP-1 preamp.   Check your particular MP-1, as three completely different jacks were used at various times over several years during the production of the MP-1.  Includes nut and washer.   Replacement nut/washer set is the JN-916.   Also see the J-575C jack, below, for the low-profile version.

Part # J-535
$6.70


Click on photo for
larger view

JACK, 6-PIN Low Profile, 1/4", ADA™.  Used as the jacks on SOME VERSIONS of the ADA MP1 effects processor.  Nut and washer are included.   Note:  Chrome trim ring on face of jack.

Part # J-575C

$6.70


Click on photo for
larger view

JACK, 1/4", Marshall™ ORIGINAL, MG SERIES, 6 Pins


Used in the Marshall™ G50RCD, G80RCD and G100RCD as the input jack.   6 pins, as shown in the photo.  No trim ring on the front of jack - only black plastic.  Low profile design.   Used only in the G50RCD, G80RCD, and G100RCD.  Includes nut and washer.


Part # J-530

$6.75


Click on photo for
larger view


JACK, 1/4",  MARSHALL, MONO, 3 PINS
Used as the input jack in the Marshall G10 MKII.    Marshall part number V9158.  No trim ring at the mouth of the jack - black plastic.  Includes nut and washer.

Part #J-9158
$6.70



Click on photo for
larger view

JACK, 9-PIN Low Profile, 1/4",  Marshall™,  Chrome Trim Ring  Used as the Effects A return jack and Effects B return jack on the rear panel of the Marshall™ DSL-50, DSL-100, TSL122 and TSL-100.  Chrome trim ring.  Jack data here.   Nut and washer are included.   Replacement nut/washer set is the JN-916.

Part # J-560C
$6.50



Click on photo for
larger view

JACK, 9-PIN Low Profile, 1/4",  Marshall™, Fender™, CHROME Trim Ring.  Used as the Effects A return jack and Effects B return jack on the rear panel of the Marshall™ DSL-50, DSL-100, TSL122 and TSL-100.  Nut and washer are included.   CHROME trim ring.  Jack data here.  Replacement nut/washer set is the JN-916.

Part # J-560
$6.50



Click on photo for
larger view

JACK, 5-PIN Low Profile, 1/4", Marshall™Chrome Trim Ring.  Used as the Effects A send jack and Effects B send jack on the rear panel of the Marshall™ DSL-50, DSL-100, TSL-122 and TSL-100.   Nut and washer are included.  Note:  Chrome trim ring on face of jack.

Part # J-565C
$6.70


Click on photo for
larger view



JACK, 1/4", Fender™, 4-PIN.  Used as the input jack on some versions of the Fender™ Sidekick amp series.  Includes nut and washer.


Part # J-6075

$5.95


Click on photo for
larger view



JACK, 9-PIN Low Profile, 1/4", Fender™.  Used in a few unique Fender models.  Nut and washer are NOT included.   Chrome trim ring.  Jack data here.  Includes nut and washer.

Part # J-560F

$6.50



Click on photo for
larger view

JACK, 1/4", Marshall™ G SERIES, INPUT, LINE OUT, FOOTSWITCH,  PC MOUNT, HAS RED STRIPE, ALSO USED IN YAMAHA, KORG, FENDER.    MONO, SWITCHED.
Used in certain Marshall™ G-series amps from the late 90s  - compare with original jack.   Back legs are slightly staggered - not positioned directly across from each other.   Check the back of the existing jack - if the back is red and the back legs are staggered, this would be the correct replacement.  NUT AND WASHER ARE INCLUDED.  Used as the input jack and the line out jack in the Marshall™ G15RCD.   Used as the input, line out and footswitch jack in the Marshall™ G30RCD.   Used as the line out, footswitch, FX send and return jacks in the Marshall™ G50RCD.   Used as the input jack on certain Fender™ SideKick amps, such as the SideKick Chorus 20.   Also used in Korg and Yamaha keyboards - Korg part number 454X851003, Yamaha part number LB202330.

Part #J-531
$4.75


Click on photo for
larger view
JACK, 1/4", CHROME NUT, CLOSED CIRCUIT, PC MOUNT, USED IN FENDER CHAMPION 600.   Input jack for the Champion 600 reissue.   Stereo T/R/S jack, no switching.  Fender part number 0073909049, 0073909000, 007-3909-049.  Nut and washer included.
Part #J-739
$3.95




WITH CHROME TRIM RING

Click on photo for
larger view

JACK, 1/4", Marshall™ ORIGINAL, MG SERIES, USED AS CD OUTPUT JACK, PC MOUNT,  ALSO USED IN YAMAHA, KORG, ROLAND, ENSONIQ.  CHROME SLEEVE.
Used in certain Marshall™ G-series amps from the late 90s - compare with original jack.   Used as the CD input jack in the Marshall™ G15RCD and the G30RCD.   Original Marshall™ part number J1031.   Used for the Headphone output of the Roland S-50 and S-770 and for the Headphone and Ext. Control jack of the Roland U-220.   It also replaces all the jacks in the Korg 01/W and 01R/W, and the CV Pedal jacks in the Ensoniq ESQ-1, ESQ-M, and SQ-80 keyboards.  The jack is equivalent to Roland part # 13449148 (YKB21-5009), Korg part # 454004400, and Behringer part # W64-01081-03178.  Used in the Behringer V-Amp and P16-M.  The chrome sleeve at the jacks opening is cosmetic.  The jack will replace equivalent jacks that have a gold sleeve or no sleeve.   Nut and washer are included.  Replacement nut/washer set is the JN-916.

Part #J-532
$4.75


4-PIN, WITH CHROME TRIM RING

Click on photo for
larger view

JACK, 1/4", STEREO, 4-PIN SWITCHED, MADE BY KOBICONN OR JALCO, USED IN  KORG, YAHAMA & OTHERS, PC MOUNT   This 4-pin, PC mount, 1/4" stereo phone jack has a normally closed tip shunt and is used in a variety of amps and keyboards made by Ensoniq, Marshall™, Ibanez, Casio, Korg, Roland and others.   Used in the Ibanez Super Metal SML stomp box, and the Casio Privia PX-310 keyboard.   It also replaces the Ensonq SQ-1, SQ-2 and SQ-R jacks and the Ensoniq ESQ-1 and ESQ-M Output jacks, Tape In & Out jacks, and Sequencer Footswitch jack.    Also replaces the Aviom A16II-HP output jack.  Shure part number 95B8329.

This jack replaces Korg part #454004400 (YKB21-5010) and Roland part #13449263 (YKB21-5005).   Nut and washer are included.   Replacement nut/washer set is the JN-916.

Part #J-53
3
$4.75


3 PIN, WITH CHROME TRIM RING

Click on photo for
larger view

JACK, 1/4", MONO, 3-PIN, INPUT, MADE BY KOBICONN,    Used in Marshall™, Korg, Yamaha, Roland, Behringer & others, PC Mount.  Chrome sleeve around jack entrance.   Gold sleeve also available, see J-539G.  Korg part number 454004300.  Behringer part number W64-01382-03176.  Roland part number 13449146.  Nut and washer are included.  Replacement nut/washer set is the JN-916.

Part #J-539
$5.75


Click on photo for
larger view



JACK, 1/4", 7-PIN, HEADPHONE,  USED IN Marshall™, FENDER™, YAMAHA™ & OTHERS, PC MOUNT
Used as the headphone jack in the Marshall™ G15RCD and G30RCD.   Original Marshall™ part number V4550.   Used as the headphone jack in Yamaha models YPR6, HE6, PSR520, YPR8, and other models.   Original Yamaha part number LB10187R.   Used in the Fender Sidekick Bass Amp as the headphone jack, Fender part number 022923.  Used in the Korg Triton Studio, Triton extreme, M3, CI8600, CI9600.  Korg part number 454005600, YKB21-5006.  Casio Part # 36120665.  Note:  No trim ring at jack opening.
   Includes nut and washer.

Part # J-540

$6.70

NUT AND WASHER, CHROME, KOBICONN OR JALCO TYPE.
Fits J-506, J-506A, J-507, J-530, J-531 , J-532, J-533, J-533G, J-539, J-539G, J-540, J-545, J-6074, J-6075, J-560.
Part #JN-916

$0.75

  British Style

Click on photo for
larger view
WASHER, FOR BRITISH STYLE (CLIFF) JACKS.
This washer goes behind the faceplate on British style plastic nut and chrome nut jacks to provide proper spacing.   Jacks come with the washers included, but the washers are easily lost.  Without the washers, the jacks will not fit properly.

Part #W-583
$0.18
for each washer.
(Jacks not included).



Click on photo for
larger view
JACK, 1/4", MONO PLASTIC, BRITISH STYLE, SOLDER TERMINALS,  CHROME NUT
4 solder terminals, switched. Used in "hand-wired" British amps, as well as other brands.  Chrome nut has male threads, jack has female threads.  With nut and washer.   Found in the Blackstar ART15, ART30 and ARTISAN100 as the input jack.  Blackstar part number MCJCK01025.
Part #J-501
$3.99


Click on photo for
larger view
JACK, 1/4", STEREO PLASTIC, BRITISH STYLE, SOLDER TERMINALS,  CHROME NUT
6 solder terminals, switched. Used in "hand-wired" British amps, as well as other brands.  Chrome nut has male threads, jack has female threads.  With nut and washer.
Part #J-501-S
$3.99


Click on photo for
larger view
JACK, 1/4", MONO PLASTIC, BRITISH STYLE, SOLDER TERMINALS,  REPLACEMENT FOR Marshall™
4 solder terminals, switched. Used in "hand-wired" amps. With nut and washer.
Part #J-502
$3.29


Click on photo for
larger view
JACK, 1/4", STEREO PLASTIC, BRITISH STYLE, SOLDER TERMINALS,  REPLACEMENT FOR Marshall™
6 solder terminals, switched. Used in "hand-wired" amps.  With nut and washer.
Part #J-505
$3.59


Click on photo for
larger view
JACK, 1/4", MONO PC MOUNT PLASTIC, BRITISH STYLE
4 PC board terminals, switched. Used in many modern Marshall™TM amp models, including the JCM900 series, JCM2000 series, the Valvestate Series 1 models, and several others.   Also used in many other brands of British amps.   With nut and washer.    Marshall part number J3B6005A or S122.
Part #J-503
$1.99


Click on photo for
larger view
SAVE WITH MULTIPACK!  JACK, 1/4", MONO PC MOUNT PLASTIC, BRITISH STYLE, PACK OF 6
4 PC board terminals, switched. Used in many modern Marshall™TM amp models, including the JCM900 series, JCM2000 series, the Valvestate Series 1 models, and several others.   Also used in many other brands of British amps.   With nut and washer.    Marshall part number J3B6005A or S122.  Pack of 6 jacks, with nuts and washers.
Part #J-503-6
$9.99
(Set of 6 jacks)



Click on photo for
larger view
JACK, 1/4", MONO PC MOUNT PLASTIC, BRITISH STYLE WITH NICKEL NUT AND CHROME TRIM RING
4 PC board terminals, switched.  Used in many brands of amps and other equipment.   Same footprint as J-503 jack - may be used in place of J-503 to add a touch of "chrome" class to your amp!   Used in newer Mesa Boogie amps, including the Rosette, Mini Rectifier, Mark 5:Twenty-Five, etc.
Part #J-603
$2.79
(per jack)



Click on photo for
larger view
JACK, 1/4", MONO PC MOUNT PLASTIC, BRITISH STYLE, WITH EMI/RFI GROUND WASHER.
Same as the J-503, with the addition of a special ground washer which contacts the chassis AND is inserted into the ground connection of the PC board via dual pins under the jack.   4 PC board terminals for signal, plus 2 additional terminals for the ground washer.   Only for amplifiers so equipped for this jack, designed
to reduced EMI/RFI interference (radio stations, ground loops).  Found in some Marshall solid state amps, as well as other brands.   Note:  Must be used only on amps designed for this type of jack that have the PCB holes to accept the pins of the ground washer.  Nut is included.
Part #J-503GW
$2.59


Click on photo for
larger view
JACK, 1/4", MONO PC MOUNT PLASTIC, BRITISH STYLE,  RED NUT, REPLACEMENT FOR Marshall™ SPEAKER JACKS.
4 PC board terminals, switched. Used in modern Marshall™TM amp heads (JCM2000 series TSL and DSL, for example) as the output jack for the speaker cabinet.  With red nut and washer.
Part #J-503R
$2.39


Click on photo for
larger view
JACK, 1/4", MONO, CLOSED CIRCUIT, PC MOUNT, BRITISH STYLE, CHROME RING
Mono jack. 4 PC board terminals, switched.  Same as J-503 jack, with the addition of the chrome ring around the entrance.  Used in Line 6™ amps as well as some other brands. Used in Electro Harmonix products.  Also found in many Engl amps (particularly on the back panels).  May be used to replace the J-503 to "upgrade" the looks of any amp using the J-503 type jack.   With nut and washer.
Part #J-503C
$2.99


Click on photo for
larger view
JACK, 1/4", MONO INPUT, CLOSED CIRCUIT, PC MOUNT, BRITISH STYLE, L-LEG Common input jack in Crate™, Ampeg™, others.  4 pins, PC mount, with nut and washer.  Note "L-Leg" pins as shown in photo.
Part #J-503L
$3.79


Click on photo for
larger view
JACK, 1/4", MONO INPUT, CLOSED CIRCUIT, PC MOUNT, BRITISH STYLE, EXTRA-TALL LEGS.  Common input jack in certain B-52™, Epiphone™™, and other specialty brand amps.   Also may be used as a replacement for the rear panel jacks FX loop jacks on the Marshall™ MG100DFX and also as the speaker jacks on the MG100HDFX.  4 pins, PC mount, with nut and washer.  Note extended straight pins as shown in photo, causing the jack to sit about 1/8" above the PC board.
Part #J-503SL
$3.45


Click on photo for
larger view
JACK, 1/4", STEREO INPUT, CLOSED CIRCUIT, PC MOUNT, BRITISH STYLE
Stereo jack. 6 PC board terminals, switched.  With nut and washer.  British style.
Part #J-504
$2.15


Click on photo for
larger view
SAVE WITH MULTIPACK!  JACK, 1/4", STEREO INPUT, CLOSED CIRCUIT, PC MOUNT, BRITISH STYLE, PACK OF 6
Stereo jack. 6 PC board terminals, switched.  Pack of 6 jacks, with nuts and washers.
Part #J-504-6
$10.99
(Set of 6 jacks)



Click on photo for
larger view

SAVE WITH OUR MULTIPACK ASSORTMENT!  THIS PACK CONTAINS THREE J-503 (4 PIN) AND THREE J-504 (6-PIN) JACKS.
Many amps contain both the 4 pin and the 6 pin British style jacks.   This assortment gives you 3 of each jack ...  Three J-503, and three J-504.

Part # J-5034-6

$10.49
(For 3 J-503 Jacks and 3 J-504 Jacks)


Click on photo for
larger view
JACK, 1/4", STEREO PC MOUNT PLASTIC, BRITISH STYLE WITH NICKEL NUT AND CHROME TRIM RING
6 PC board terminals, switched.  Used in many brands of amps and other equipment.   Same footprint as J-504 jack - may be used in place of J-504 to add a touch of "chrome" class to your amp!   Used in newer Mesa Boogie amps, including the Rosette, Mini Rectifier, Mark 5:Twenty-Five, etc.
Part #J-604
$2.99
(per jack)



Click on photo for
larger view
JACK, 1/4", T/R/S PC MOUNT PLASTIC, BRITISH STYLE, WITH EMI/RFI GROUND /WASHER.
Same as the J-504, with the addition of a special ground washer which contacts the chassis AND is inserted into the ground connection of the PC board via dual pins under the jack.   6 PC board terminals for signal, plus 2 additional terminals for the ground washer.   Only for amplifiers so equipped for this jack, designed
to reduced EMI/RFI interference (radio stations, ground loops).  Found in some Marshall solid state amps, as well as other brands.   Note:  Must be used only on amps designed for this type of jack that have the PCB holes to accept the pins of the ground washer.  Nut is included.
Part #J-504GW
$2.89


Click on photo for
larger view
JACK, 1/4", STEREO, CLOSED CIRCUIT, PC MOUNT, BRITISH STYLE, CHROME RING
Stereo jack. 6 PC board terminals, switched.  Same as J-504 jack, with the addition of the chrome ring around the entrance.  Used in Line 6™ amps as well as some other brands.  Line 6 part number 21-00-6616.   Also used in Electro Harmonix products.  Also found in many Engl amps (particularly on the back panels).  May be used to replace the J-504 to "upgrade" the looks of any amp using the J-504 type jack.   With nut and washer.
Part #J-504C
$3.50


Click on photo for
larger view
JACK, 1/4", STEREO, CLOSED CIRCUIT, PC MOUNT, BRITISH STYLE, L-LEG Common input jack in Crate™, Ampeg™, others.  6 pins, PC mount, with nut and washer.   Note "L-Leg" pins as shown in photo.
Part #J-504L
$3.95


Click on photo for
larger view
JACK, 1/4", STEREO INPUT, CLOSED CIRCUIT, PC MOUNT, BRITISH STYLE, EXTRA-TALL LEGS.   May be used as a replacement for the footswitch jack on the Marshall™ MG100HDFX.  6 pins, PC mount, with nut and washer.  Note extended straight pins as shown in photo, causing the jack to sit about 1/8" above the PC board.  Used as the output jack on the Orange DT30.
Part #J-504SL
$3.95


Click on photo for
larger view

JACK, 1/4", MONO 4-PIN, PC MOUNT, Fender  Fender PCB mount 1/4" jack. Tip/Sleeve, 4 pin. Used as the input jacks on the Fender Mustang amps (I through IV).   Used as the footswitch jack on the Ultimate Chorus DSP Amp from 2000-2002.  Also used on some Squier models.   Nut is included.   Original Fenderpart numbers 0091653000 and 0051658000.
Part #J-517

$2.95


Click on photo for
larger view
JACK, 1/4", STEREO 6-PIN, PC MOUNT, Fender  Fender PCB mount 1/4" jack. Tip/Ring/Sleeve, 6 pin. Used as the effects jacks and headphone jacks on the Fender Mustang amps (III through V).  Used as the input (insert) jack Also used as the input jacks and all FX Loop Jacks on the Ultimate Chorus DSP Amp from 2000-2002.   Nut is included.   Original Fenderpart numbers 0091655000 and 0053450000.
Part #J-514
$3.50



Click on photo for
larger view

Note:  Nut NOT included - reuse original, or order J-510.

JACK, 1/4", STEREO, REAN TYPE, PC MOUNT, Fender,  others.
Fender
PCB mount 1/4" jack.  Fender™ part number 0053450000.   Stereo, 6 pin. Fits certain Fender amp models 1999 - present.   Nut NOT included.   Reuse existing nut or order nut separately as part #J-510.
Part #J-508

$2.95



Click on photo for
larger view

Note:  Nuts NOT included - reuse original, or order J-510.

SAVE WITH MULTIPACK!  JACKS, 1/4", STEREO 6-PIN, REAN TYPE, PC MOUNT, Fender, Peavey, others.   SET OF 6 JACKS.
Fender
PCB mount 1/4" jack.  Fender™ part number 0053450000.  Stereo, 6 pin.  Fits certain Fender amp models 1999 - present.  Set of 6 Jacks.  Nuts NOT included.   Reuse existing nuts or order nuts separately as part #J-510.
Part #J-508-6

$12.95
(For Set of 6 Jacks)



Click on photo for
larger view

Note:  Nut NOT included - reuse original, or order J-510.

JACK, 1/4", MONO, REAN TYPE, PC MOUNT, Fender.
Fender
PCB mount 1/4" jack. Mono, 4 pin. Fits certain Fender amp models 1999 - present (including certain jacks on the newer Hot Rod Deluxe & Deville, and Blues Deluxe & Deville).   Fender™ part number 0051658000.   Nut NOT included.   Reuse existing nut or order nut separately as part #J-510.
Part #J-509

$2.95



Click on photo for
larger view

Note:  Nut NOT included - reuse original, or order J-510 or J-5NT, below.

SAVE WITH MULTIPACK!  JACKS, 1/4", MONO 4-PIN, REAN TYPE, PC MOUNT, Fender.   SET OF 6 JACKS.
Fender
PCB mount 1/4" jack. Mono, 4 pin. Fits certain Fender amp models 1999 - present (including certain jacks on the newer Hot Rod Deluxe & Deville, and Blues Deluxe & Deville).  Fender™ part number 0051658000.   Set of 6 Jacks.   Nuts NOT included.   Reuse existing nut or order nut separately as part #J-510.
Part #J-509-6

$12.95
(For Set of 6 Jacks)


Click on photo for
larger view

JACK, 1/4", MONO 4-PIN, PC MOUNT, Peavey and Gallien-Krueger AMPS
Peavey
PCB mount 1/4" jack. Tip/Sleeve, 4 pin. Fits certain Peavey and Gallien-Krueger models (including the G-K Backline 210 and some of the G-K RB series, such as the 1001RB-II).  Peavey part number 71466322.  Gallien-Krueger part number 092-0081-0.  Also fits some versions of the Bugera V-22 Infinium series - check your specific amp for compatibility.  Black nut is included.   For savings on multiple jacks, see the J-519-6 jack set below.
Part #J-519

$2.95


Click on photo for
larger view

SAVE WITH MULTIPACK!  JACK, 1/4", TIP/SLEEVE 4-PIN,  PC MOUNT, Peavey and Gallien-Krueger AMPS, SET OF 6 JACKS.
Peavey
PCB mount 1/4" jack. Tip/sleeve, 4 pin. Fits certain Peavey and Gallien-Krueger models (including the G-K Backline 210 and some of the G-K RB series, such as the 1001RB-II).  Peavey part number 71466322. Gallien-Krueger part number 092-0081-0.  Set of 6 jacks, black nuts are included.
Part #J-519-6

$14.95
(For Set of 6 Jacks)


Click on photo for
larger view

JACK, 1/4", TIP/RING/SLEEVE 6-PIN, PC MOUNT, Peavey AMPS
Peavey
PCB mount 1/4" jack. Stereo, 6 pin. Fits certain Peavey and Gallien-Krueger amp models.  Peavey part number 31646323 or 71466323.  Black nut is included.  For savings on multiple jacks, see J-518-6 below.
Part #J-518

$3.50


Click on photo for
larger view

SAVE WITH MULTIPACK!   JACK, 1/4", TIP/RING/SLEEVE 6-PIN, PC MOUNT, Peavey AMPS, SET OF 6 JACKS.
Peavey
PCB mount 1/4" jack. Stereo, 6 pin. Fits certain Peavey and Gallien-Krueger amp models.  Peavey part number 31646323 or 71466323.  Black nuts are included.  Set of 6 jacks.
Part #J-518-6

$14.95
(For Set of 6 Jacks)


Click on photo for
larger view
JACK, 1/4", CHROME NUT, CLOSED CIRCUIT, PC MOUNT, BRITISH STYLE, L-LEG, TIP-SLEEVE, 4 PINS.   Generally found only in Crate or Ampeg products.   Common input, footswitch or effects loop jack exclusive to Crate™ and Ampeg™.   (Other brands with chrome-nut jacks use a straight pin jack such as the J-580.)  4 pins, PC mount, with chrome nut and washer.   Note "L-Leg" pins as shown in photo.   Original Crate or Ampeg part number 39-119-01.
Part #J-580L

$4.59


Click on photo for
larger view
JACK, 1/4", CHROME NUT, CLOSED CIRCUIT, PC MOUNT, EXTENDED PCB PINS, TIP-RING-SLEEVE, 6 PINS.   Usually found in amplifiers or pedals built in China or Taiwan.   Frequently used in Kustom® products.  6 pins, PC mount, with chrome nut and washer.   Note "extended" pins as shown in photo.   For data sheet showing dimensions, click here
Part #J-581SL
$3.95


Click on photo for
larger view
JACK, 1/4", CHROME NUT, CLOSED CIRCUIT, PC MOUNT, BRITISH STYLE, L-LEG, TIP-RING-SLEEVE, 6 PINS.   Generally found only in Crate or Ampeg products.  Common input, footswitch or effects loop jack exclusive to Crate™, Ampeg™.   (Other brands with chrome-nut jacks use a straight pin jack such as the J-581.)  6 pins, PC mount, with chrome nut and washer.   Note "L-Leg" pins as shown in photo.   Original Crate or Ampeg part number 39-120-01.
Part #J-581L
$3.95


Click on photo for
larger view
JACK, 1/4", MONO, CLOSED CIRCUIT, PC MOUNT, BRITISH STYLE - WHITE   Identical to the J-503 above, except in white.  How cool is that!  Mono input jack. 4 PC board terminals, switched. Used in modern Marshall™ amps, as well as many other brands.  With nut and washer.
Part #J-555
$3.99


Click on photo for
larger view
JACK, 1/4", STEREO, CLOSED CIRCUIT, PC MOUNT, BRITISH STYLE - WHITE   Identical to the J-504 above, except in white.  How cool is that!  Stereo jack. 6 PC board terminals, switched. Used in modern Marshall™ amps, as well as many other brands. Used in many PA and recording consoles, Marshall™ bass heads, Line 6™ amps, and "rack" units.   With nut and washer.
Part #J-556
$3.99


Click on photo for
larger view
JACK, 1/4", MONO INPUT, CLOSED CIRCUIT, PC MOUNT, BRITISH STYLE, STRAIGHT LEG (NOT L-LEG!)
Common input jack found in some "boutique" and independent brand amps, as well as Marshall™ , B52, Trace Elliot, Orange, etc.  NOT used in Crate™, Ampeg™. 4 PC board terminals.  Chrome nut has male threads, jack has female threads.  Leads from jack come straight down from the contacts to go into the PC board.   With nut and washer.
Part #J-580
$3.99


Click on photo for
larger view
JACK, 1/4", STEREO INPUT, CLOSED CIRCUIT, PC MOUNT, BRITISH STYLE, STRAIGHT LEG (NOT L-LEG!)
Common input jack found in some "boutique" and independent brand amps, as well as Marshall™ , B52, Trace Elliot, Orange, and Dunlop™/MXR products.  NOT used in Crate™, Ampeg™ (see J-581L for those).   6 PC board terminals.  Chrome nut has male threads, jack has female threads.  Leads from jack come straight down from the contacts to go into the PC board.   With nut and washer.
Part #J-581
$4.49


Click on photo for
larger view
JACK, STEREO, MXR / DUNLOP TYPE WITH EXTRA RING CONTACT
Exclusive Dunlop jack - used in several MXR pedals.  Has additional off-normal contact on the ring conductor.  Chrome nut is included.
Part #D-ECB040
$5.95



Click on photo for
larger view
JACK NUT, PLASTIC, BRITISH STYLE, REPLACEMENT FOR Marshall™ AND OTHERS.   Note:     Replaces most black plastic jack nuts EXCEPT for Roland.    Will NOT fit Roland jacks.
Replacement jack nut as found on the J-502, J-503, J-504, J-505, J-503L and J-504L jacks.   Also fits the J-518 and J-519 jacks.
Part #J-5NT
$0.50


Click on photo for
larger view
JACK NUT MULTI-PACK - SAVE!   6 JACK NUTS, PLASTIC, BRITISH STYLE, REPLACEMENT FOR Marshall™ AND OTHERS.   Note:     Replaces most black plastic jack nuts EXCEPT for Roland.    Will NOT fit Roland jacks.
Replacement jack nut as found on the J-502, J-503, J-504, J-505, J-503L and J-504L jacks.   Also fits the J-518 and J-519 jacks.
Part #J-5NT-6
$2.39


Click on photo for
larger view
JACK NUT, PLASTIC, BRITISH STYLE, RED
Replacement nut for the J-503, J-504.
Red nuts on these jacks typically are used on later model Marshall™ amps to designate the 'speaker' jacks.
Part #J-5NTR
$0.89


Click on photo for
larger view
JACK NUT, PLASTIC, BRITISH STYLE, WHITE
Replacement nut for the J-555 and J-556 jacks.
Will also fit the J-502, J-503, J-504, J-505, J-503L and J-504L black jacks, if you wish to create a two-tone effect.
Part #J-5NTW
$0.60


Click on photo for
larger view
JACK NUT/FERULE, CHROME, with BLACK PLASTIC BEZEL/WASHER - BRITISH CLIFF STYLE
Replacement nut and bezel washer for the J-501, J-501S, J-580, J-581, J-580L and J-581L jacks.   Note:   The threads on this nut are coarse (3/8-20), and are for genuine Cliff jacks.   Note:
There are some generic jacks on the market with finer thread nuts.   This nut will not fit those jacks.   This nut is for BRITISH CLIFF STYLE jacks.   Bezel is included with this nut.
Part #JN-200W
$1.15


Click on photo for
larger view
JACK NUT/FERULE, BLACK, with INTEGRAL  BLACK PLASTIC BEZEL - BRITISH STYLE
Replacement nut and bezel washer which will fit the J-501, J-501S, J-580, J-581, J-580L, and J-581L jacks.   Note:   The threads on this nut are coarse (3/8-20), and are for genuine Cliff UK jacks.   Note:
There are some generic jacks on the market with finer thread nuts.   This nut will not fit those jacks.   This nut is for genuine Cliff UK jacks.   Bezel is integral to the nut and cannot be removed.   This is the jack nut used on the Marshall JMP-1 Preamp, and on some versions of the Marshall DRP-1 Direct Recording Preamp.
Part #JN-864
$0.89



Click on photo for
larger view

JACK, 1/4", Used in Peavey, PCB, MONO CLOSED CIRCUIT
PCB mono closed circuit.   Original Peavey part numbers 31466164,
71466164, and 71466088.  Found in the Peavey KB60, KB300, Studio Chorus 210, some versions of the Basic 112, Micro Bass (original version), Rage 158, and other models.  Includes nut and washer.

Part #J-525
$9.50



Click on photo for
larger view
JACK, 1/4", PC MOUNT, STEREO, 5 PINS, SWITCHED, INSULATED.  Original Peavey part number 31466167 and 71466167. Used as the headphone jack in the KB/A 60 keyboard amp.  Also found in some other Peavey products.  Insulated bushing for ground isolation from the chassis. Nut and washer included.

Part #J-526
$6.99



Click on photo for
larger view
JACK, 1/4", PC MOUNT, STEREO, 3 PINS, SWITCHED, INSULATED.   Used in many Peavey™ and SWR™ models.  Original Peavey™ part number 71466165.   Original SWR™ part number 0066442000.   Nut and washer are included.  3 pins.
Part #J-526A
$7.75



Click on photo for
larger view
JACK, 1/4", PC MOUNT, STEREO, 6 PINS, SWITCHED, INSULATED.    Original Peavey part number 31466165 and 71466165.  Found in some versions of the 5150, 6505, 5150-II and 6505+, as well as the pre-EQ jack on the KB60.  Used as the input jack on the older version of the Basic 112.  Nut and washer included.

Part #J-625
$8.95


Click on photo for
larger view
SAVE WITH MULTIPACK!  JNUT-38 JACK NUT AND WASHER, METAL, SWITCHCRAFT, SET OF 6
Genuine Switchcraft™ nut and washer set for the blackface/silverface Fender™ bias pot, Mesa Boogie pots, and the CTS or Alpha pots with 3/8" bushing (found on original vintage Fender™ blackface and silverface), as well as Peavey™ and Switchcraft™ 1/4" jacks.  Does NOT fit the 24mm Marshall™ pots.   Set of 6 washers and 6 nuts.
Part #JNUT-38-6
$4.50
(Set of 6 washers and 6 nuts)



Click on photo for
larger view
JACK NUT AND WASHER, METAL, SWITCHCRAFT
Genuine Switchcraft™ nut and washer set for the blackface/silverface Fender™ bias pot, Mesa Boogie pots, and the CTS or Alpha pots with 3/8" bushing (found on original vintage Fender™ blackface and silverface), as well as Peavey™ and Switchcraft™ 1/4" jacks.  Does NOT fit the 24mm Marshall™ pots.
Part #JNUT-38
$0.89
(Set of 1 washer and 1 nut)



Click on photo for
larger view.   Jack is in the picture to demonstrate how the washers are installed - jack is NOT included with the washers.
INSULATING SHOULDER WASHER, FIBER
Pair of fiber insulating shoulder washers for Switchcraft jacks with metal bushings.   Used to mount standard jacks in a 1/2" diameter chassis hole, while insulating the metal bushing (ground) of the jack from the chassis.   ID 3/8", OD 1/2".  Works great when replacing isolated plastic jacks with a more durable metal jack, which is frequently done on the input jacks of the Fender™ Hot Rod Deville/Deluxe and Blues Deville/Deluxe.   Two washers are used on each jack, and the "shoulders" are placed facing each other through the chassis.   The washers not only isolate the ground of the jack electrically for noise reduction, but also stabilize the jack in the 1/2" diameter hole.   Jack shown in picture NOT included.   Works well with the Switchcraft J-11, J-L11, J-12A, J-L12A, J-12B, J-L12B, J-13, J-13A, J-112APC, J-112BX, J-114BX, J-521 and J-524 jacks.
Part #ISW-3069
$0.49
(For a pair of washers.  Each jack needs two washers.)




Click on photo for
larger view

Note:  Nut NOT included - reuse original, or order J-510.

JACK, 1/4", STEREO, REAN TYPE, PC MOUNT, Fender
Fender
PCB mount 1/4" jack.  Fender™ part number 0053450000.   Stereo, 6 pin. Fits certain Fender amp models 1999 - present (including certain jacks on the Hot Rod Deluxe & Deville, and Blues Deluxe & Deville).  Nut NOT included.   Reuse existing nut or order nut separately as part #J-510.
Part #J-508

$2.95



Click on photo for
larger view

JACK, 1/4", MONO, PC MOUNT, SHORT THREAD, PEAVEY
PCB mount 1/4" jack. Mono, 4 pin, PC board mount. Used in several versions of the Peavey ValveKing amplifiers, the MP4 Plus Powered Mixer, and the later versions of the Basic 112.  Nut is included.   Peavey part number 71466222 and 31466322.

Part #J-661

$ 3.79
(per jack)



Click on photo for
larger view

JACK, 1/4", STEREO, PC MOUNT, SHORT THREAD, PEAVEY
PCB mount 1/4" jack. Mono, 6 pin, PC board mount. Used in several versions of the Peavey ValveKing amplifiers.  Also used in the Tour TKO Amp.  Peavey part number 31466323.  Nut is included.

Part #J-662

$ 3.99
(per jack)



Click on photo for
larger view

JACK, 1/4", STEREO, REAN TYPE, PC MOUNT, Metal 3/8" Threads, Fender AMPS 1998 - Present.
Fender
PCB mount 1/4" jack. Stereo, 6 pin.  Fender™ part number 0059889000.  Princeton™ Recording Amp, Jazz-King™, TB 600/1200, Bassman™ TV Series, Super Bassman™ (2012), Machete™, Acoustasonic™ SFX II, Princeton™ 650, Deluxe™ 900, Stage™ 1000/1600, EVH 5150III, Cyber-Twin™ SE, JazzMaster™ Ultralight, Bassman™ 250, Steel King and Super-Champ™ X2 amplifiers (1998-present).   Identical to J-508 jack above, except for the metallic threads, which uses a different size nut.  Nut and washer are included.
Part #J-563

$ 4.75



Click on photo for
larger view

JACK, 1/4", STEREO, REAN TYPE, PC MOUNT, Metal 3/8" Threads, Grounding type,  Fender AMPS 1998 - Present.
Fender
PCB mount 1/4" jack. Stereo, 6 pin.  Fender™ part number 0079774000.  Shield grounded to chassis via metal bushing, tip and ring switched.  Nut and washer are included.
Part #J-564

$ 4.75



Click on photo for
larger view

Note:  Nut NOT included - reuse original, or order J-510 or J-5NT, below.

JACK, 1/4", STEREO, REAN TYPE, PC MOUNT, Half-thread (Bullnose)
PCB mount 1/4" jack. Stereo, 6 pin. Identical to J-508 jack above, except for the shorter threads. Used in many models of guitar amps, mixers and power amps, including Yorkville.   Korg part number CON0010058.   Found in Korg PA600, SV1, PA3X, PA300, PA700.  Nut NOT included.   Reuse existing nut or order nut separately as part #J-510.  Note: You can also use the black plastic Cliff nut on this jack, and some models are designed that way.  If you need the black plastic nut to fit this jack, order #J-5NT, further down this page.
Part #J-562

$ 3.95



Click on photo for
larger view

Note:  Nut NOT included - reuse original, or order J-5NT, below.

JACK, 1/4", MONO, REAN TYPE, PC MOUNT, Half-thread (Bullnose)
PCB mount 1/4" jack. Mono, 4 pin. Identical to J-509 jack above, except for the shorter threads. Used in many models of guitar amps, mixers and power amps, including Yorkville.  Nut NOT included.   Reuse existing nut or order #J-5NT, further down this page.
Part #J-561

$ 3.50


Click on photo for
larger view

NUT, NICKEL, REAN TYPE, Fender, AMPS 1999 - Present.
Fender
nut, fits J-508 and J-509 jacks.   (Note:  you can use this nut on the Cliff J-502, J-503, J-504, J-505, J-503L and J-504L jacks as well, if you wish to change your amps appearance.)
Part #J-510

$ 0.85


Click on photo for
larger view
JACK, SPEAKON, CHASSIS-MOUNT - MADE FOR WIRE ATTACHMENT (3/16" PUSH ON CONNECTORS OR SOLDER TABS).   Made by Neutrik. 4 pins (1+, 1-, 2+, 2-) Used in a variety of brands, including Peavey™.

Part #J-NL4MP
$4.95


Click on photo for
larger view
JACK, COMBINATION XLR and 1/4", CHASSIS-MOUNT - FOR PC BOARD, VERTICAL MOUNT.   Made by Neutrik # NCJ6FA-V. Exact replacement for for many combo XLR-1/4" jacks.  With push latch as shown.  Download the complete engineering drawing showing the pin layout here.
Part #J-NCJ6FA-V
$5.99


Click on photo for
larger view

Neutrik Rean NYS221 1/4" Stereo Jack Thick Panel
1/4" phone jack for thick panels, guitar bodies, etc. with special designed head for guitar strap, 3-pole (TRS), long-threaded bushing with washer and nut, and full metal housing.
Part #NYS221

$4.50

  Miscellaneous

Click on photo for
larger view
RCA JACK, PANEL MOUNT  Exact replacement for the reverb tank and footswitch jacks on the rear panel of Fender™ Blackface and Silverface amplifiers.  Made by Switchcraft.   Nut is included.
Part #J-122
$2.99


Click on photo for
larger view
Revisit™ RCA JACK, PANEL MOUNT, CHROME, PHENOLIC BASE MOUNTED - FENDER™ TWEED AMPS SPEAKER JACK.  RCA Phono Jack, chassis mount. 11/16" mounting hole spacing, black phenolic base, round.  Chrome RCA jack.  Used as the speaker jack in some Fender Tweed amps from the 1950s, as well as the Fender™ blackface and silverface Champ, VibroChamp and Bronco Amps from the 60s and 70s.  Also used in vintage USA-Made Accutronic Reverb Tanks made before 2010.   Black phenolic base.
Part #J-351
$3.50


Click on photo for
larger view
FENDER HEADPHONE AND AUXILIARY JACK - MUSTANG AMPLIFIERS  Fender part number 0082046000.   Used only in the Mustang series of amps as the 1/8" stereo headphone or aux jack.
Part #J-820
$5.99


Click on photo for
larger view
MARSHALL MINI-JACK, STEREO, 3.5mm
Used as the Line Out, Headphone, or Music Source Input Jack on the MG15CFX, MG30CFX, MG50CFX, MG100CFX, MG15FX, MG30FX, MG50FX, MG100FX, MG15GFX, MG30GFX, MG50GFX, MG100GFX.   Accepts 1/8 inch or 3.5mm stereo mini-plugs.
Part #J-355
$2.50


Click on photo for
larger view
USB CONNECTOR, "B" type.   USED IN YAMAHA, KORG, ROLAND, Others. Korg part number CON0001079, as found in the Korg SV1-73, and Triton Extreme.  Also found in the Access Virus T1, Akai MPK49 and MPK61, Alesis Q25, Q49, QX25, QX49, Dave Smith Prophet 12, Edirol PCR Series, M-Audio Axiom 49, Axiom Pro 49, Axiom 61, Axiom Pro 61, KeyRig Series, Keystation Series and Key Studio, Roland PCR Series Controllers, and Yamaha MM6, MM8, and S90, as well as other brands and models not listed.  Line 6 part number 21-21-0001, as found in many Line 6 guitar processors.
Part #J-437
$1.29


Click on photo for
larger view
USB CONNECTOR, "A" type.   USED IN YAMAHA, KORG, ROLAND, Others.   "A" Type USB connector, found in a number of keyboards, processors, professional audio gear made by many manufacturers.   Right-angle PC mount 4-conductor.    Industry standard USB.
Part #J-427
$1.29


Click on photo for
larger view
JACK PLATE, BLACK METAL, SINGLE 1/4" JACK, 2" OUTSIDE DIAMETER. Similar in style to vintage Fender™ jack plates.  Works well with the Switchcraft J-11 1/4" jacks that we carry. Hole is 3/8", for most Switchcraft type jacks.  Easy to install, economical.   Includes 3 black oxide coarse-thread mounting screws, #6x3/4".   Jack not included - order separately.   For size specifications, click here.
Part #JP-180
$1.89



Click on photo for
larger view
Revisit™ JACK PLATE COMPLETE WITH SWITCHCRAFT #11 JACK.  Switchcraft #11 jack preinstalled with lock washer and trim washer. Outside diameter 2 inches (51mm). Minor assembly required. Designed to fit flush against a 1 1/8" (29mm) cabinet hole. Easy to install - drill 1 1/8" hole in cabinet, attach speaker wiring to jack and speaker, attach plate to cabinet.
Part #JPC-180
$4.95



Click on photos for
larger views

JACK PLATE, MONO/STEREO, PLUG AND PLAY
This unit eliminates the confusing switch found on most stereo cabinets. Just pick your impedance and plug in. Labels shows the common 4 or 16 Ohm Mono and 8 Ohm Stereo option. Ready to install with a steel dish, wires, and speaker connectors already assembled - as shown in the photo.  Requires a 3 inch x 3-7/16 inch rectangular hole cut in the cabinet.  Direct easy replacement for many existing small jack dishes.   No soldering required.  Complete wiring directions included - click here for more details.  Designed to be used with 2x12 cabinets containing two 8-ohm speakers, 4x12 cabinets with four 16-ohm speakers, or 4x12 cabinets with four 4-ohm speakers.  Can be used for the following configurations:
  • 4 ohm mono
  • 8 ohm left + 8 ohm right stereo
  • 8 ohm left only mono
  • 8 ohm right only mono
  • 16 ohm mono

Part #CJP-1

$35.95


Click on photo for
larger view

DC POWER JACK
Handy way to add a power jack for an AC/DC Adapter to an existing devices.   Connector fits the popular 2.1mm x 5.5mm barrel plug found on many adapters.   Normally closed switch, so that an internal battery may be switched on or off automatically as the adapter is connected.   Plastic housing isolates both conductors, so it may be used for either center positive or center negative adapters.  Fits 1/2" chassis hole.
Part #J-750
$1.49


Click on photo for
larger view

DC POWER JACK
Replacement Barrel DC power jack for many pedals, keyboards, etc which use a PC board mounted DC power jack.  Connector fits the popular 2.1mm x 5.5mm barrel plug found on many adapters.   Normally closed switch, so that an internal battery may be switched on or off automatically as the adapter is connected.   Plastic housing isolates both conductors, so it may be used for either center positive or center negative adapters.
Part #BJK-118
$0.99


Click on photo for
larger view

1/8" MINI JACK
Switched two-conductor 1/8" mini jack.  Exact replacement for the DC power jack used in the vintage Electro-Harmonix Big Muff and Small Stone, Proco Rat Big Box Reissue and others.
Part #J-218
$0.99


Click on photo for
larger view

POWER BARREL PLUG
Replacement barrel power plug for many AC adapters.  Connector is the popular 2.1mm x 5.5mm barrel plug found on many adapters.   Soldering required to attach to cable.
Part #BP-573
$0.99


Click on photo for
larger view

Dual Chassis-Mount Banana Binding Posts.   Used on the rear panel of many power amplifiers.  Red and black posts, accepts either single or dual banana plugs. Mounts in two 1/2" holes on 3/4" centers, panel thickness up to 1/4". 15A rating, gold plated contacts.
Part #BP-263

$9.95


Click on photo for
larger view
Peavey binding post, pc mount, black.   Found on several models of Peavey power amplifiers.   Red type also available, below.  Fits standard banana plugs.
Part #BP-277
$6.50


Click on photo for
larger view
Peavey binding post, pc mount, red.   Found on several models of Peavey power amplifiers.   Black type also available, above.  Fits standard banana plugs.
Part #BP-278
$6.50

We only have one BP-278 left in stock!


Click on photo for
larger view
JACK, CHASSIS MOUNT, DIN, 6 PINS
This jack is commonly used as the footswitch connector on many Peavey™ guitar amps.  Also used by Genz Benz and other manufacturers.

Part #J-520
$3.99


Click on photo for
larger view
JACK, CHASSIS MOUNT, DIN, 7 PINS
This jack is commonly used as the footswitch connector on many Peavey™ guitar amps.  Also used by Mesa Boogie, Genz Benz and other manufacturers.

Part #J-516
$3.99


Click on photo for
larger view
JACK, CHASSIS MOUNT, DIN, 8 PINS
This jack is commonly used as the footswitch connector on many Peavey™ guitar amps.  Also used by Genz Benz and other manufacturers.

Part #J-528
$3.99

  Jack Nuts and Washers

Click on photo for
larger view
SAVE WITH MULTIPACK!  JNUT-38 JACK NUT AND WASHER, METAL, SWITCHCRAFT, SET OF 6
Genuine Switchcraft™ nut and washer set for the blackface/silverface Fender™ bias pot, Mesa Boogie pots, and the CTS or Alpha pots with 3/8" bushing (found on original vintage Fender™ blackface and silverface), as well as Peavey™ and Switchcraft™ 1/4" jacks.  Does NOT fit the 24mm Marshall™ pots.   Set of 6 washers and 6 nuts.
Part #JNUT-38-6
$4.50
(Set of 6 washers and 6 nuts)



Click on photo for
larger view
JACK NUT AND WASHER, METAL, SWITCHCRAFT
Genuine Switchcraft™ nut and washer set for the blackface/silverface Fender™ bias pot, Mesa Boogie pots, and the CTS or Alpha pots with 3/8" bushing (found on original vintage Fender™ blackface and silverface), as well as Peavey™ and Switchcraft™ 1/4" jacks.  Does NOT fit the 24mm Marshall™ pots.
Part #JNUT-38
$0.89
(Set of 1 washer and 1 nut)



Click on photo for
larger view
WASHER, FOR BRITISH STYLE (CLIFF) JACKS.
This washer goes behind the faceplate on British style plastic nut and chrome nut jacks to provide proper spacing.   Jacks come with the washers included, but the washers are easily lost.  Without the washers, the jacks will not fit properly.

Part #W-583
$0.18
for each washer.
(Jacks not included).


NUT AND WASHER, NICKEL, KOBICONN OR JALCO TYPE.
Fits J-506, J-506A, J-507, J-530, J-531 , J-532, J-533, J-533G, J-539, J-539G, J-540, J-545, J-6074, J-6075, J-560.
Part #JN-916

$0.75


Click on photo for
larger view

NUT, NICKEL, REAN TYPE, Fender, AMPS 1999 - Present.
Fender
nut, fits J-508 and J-509 jacks.   (Note:  you can use this nut on the Cliff J-502, J-503, J-504, J-505, J-503L and J-504L jacks as well, if you wish to change your amps appearance.)
Part #J-510

$ 0.85


Click on photo for
larger view
JACK NUT, PLASTIC, BRITISH STYLE, REPLACEMENT FOR Marshall™ AND OTHERS.   Note:     Replaces most black plastic jack nuts EXCEPT for Roland.    Will NOT fit Roland jacks.
Replacement jack nut as found on the J-502, J-503, J-504, J-505, J-503L and J-504L jacks.   Also fits the J-518 and J-519 jacks.
 Part #J-5NT
$0.50


Click on photo for
larger view
JACK NUT MULTI-PACK - SAVE!   6 JACK NUTS, PLASTIC, BRITISH STYLE, REPLACEMENT FOR Marshall™ AND OTHERS.   Note:     Replaces most black plastic jack nuts EXCEPT for Roland.    Will NOT fit Roland jacks.
Replacement jack nut as found on the J-502, J-503, J-504, J-505, J-503L and J-504L jacks.   Also fits the J-518 and J-519 jacks.
 Part #J-5NT-6
$2.39


Click on photo for
larger view
JACK NUT, PLASTIC, BRITISH STYLE, RED
Replacement nut for the J-503, J-504.
Red nuts on these jacks typically are used on later model Marshall™ amps to designate the 'speaker' jacks.
Part #J-5NTR
$1.00


Click on photo for
larger view
JACK NUT, PLASTIC, BRITISH STYLE, WHITE
Replacement nut for the J-555 and J-556 jacks.
Will also fit the J-502, J-503, J-504, J-505, J-503L, J-504L, J-518 and J-519 black jacks, if you wish to create a two-tone effect.
Part #J-5NTW
$1.00


Click on photo for
larger view
JACK NUT/FERULE, CHROME, with BLACK PLASTIC BEZEL/WASHER - BRITISH CLIFF STYLE
Replacement nut and bezel washer for the J-501, J-501S, J-580, J-581, J-580L and J-581L jacks.   Note:   The threads on this nut are coarse (3/8-20), and are for genuine Cliff jacks.   Note:
There are some generic jacks on the market with finer thread nuts.   This nut will not fit those jacks.   This nut is for BRITISH CLIFF STYLE jacks.   Bezel is included with this nut.
Part #JN-200W
$1.15


Click on photo for
larger view
JACK NUT/FERULE, BLACK, with INTEGRAL  BLACK PLASTIC BEZEL - BRITISH STYLE
Replacement nut and bezel washer which will fit the J-501, J-501S, J-580, J-581, J-580L, and J-581L jacks.   Note:   The threads on this nut are coarse (3/8-20), and are for genuine Cliff UK jacks.   Note:
There are some generic jacks on the market with finer thread nuts.   This nut will not fit those jacks.   This nut is for genuine Cliff UK jacks.   Bezel is integral to the nut and cannot be removed.   This is the jack nut used on the Marshall JMP-1 Preamp, and on some versions of the Marshall DRP-1 Direct Recording Preamp.
Part #JN-864
$0.89



Copyright ©2024 Studio Sound Electronics - All Rights Reserved
Not responsible for web site errors or omissions.
  WARNING: These products may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov
