Fender™ Switches

We carry a complete selection of Fender™ Amplifier parts for both vintage and modern amps.

Back to Fender™ Parts Index




Description

Price Purchase

Click on photo for
larger view
ORIGINAL Fender™ PUSH SWITCH
DPDT Mini Short-Throw Push Switch.  Has 6 electrical terminals on bottom of switch (DPDT).  Used for channel switching, FX switching on the front panels of many Fender™ amps from the 1990s to present.    Found in the Acoustasonic  series, Blues Deville, Blues Deluxe, Blues Jr., Bullet Reverb, Bullet Reverb, Bassman 300, BXR100, Champion 30, Champion 30 DSP, Champion 110, Frontman 25R, Frontman 25G, Hot Rod Deville, Hot Rod Deluxe, Deluxe 112 & 112 Plus, Roc Pro series, Performer 1000, Princeton 65, Princeton 65 DSP, Princeton 112 & 112 Plus, PCN-2, PCN-4, SFX, Super-Sonic, Cyber Twin series, Satellite Ultimate Chorus, Super Champ X2, Super Champ XD, Twin Amp Pro Tube, and others.   Original Fender™ part number 0028091000.   Also Fender™ part number 028091, and 028091049.  Has actuator shaft of 2.7mm square.
Part #SW-028
$4.95


Click on photo for
larger view
ORIGINAL Fender™ PUSH SWITCH
4PDT Mini Short-Throw Push Switch.  Has 12 electrical terminals on bottom of switch (4PDT).   Used as the Enhance switch on the Fender™ Bassman 25.   Used as the Effects Level switch (rear panel) on the Cyber Twin combo, Cyber Twin head, Cyber Twin SE, and the TBP-1 Preamp.  Original Fender™ part number 0038828000.    Switch only - see part number K-058 for the switch cap.
Part #SW-828
$6.95


Click on photo for
larger view

Hex footswitch nut, pack of 4

These replacement nuts fit all Carling brand footswitches and toggle switch and some (but not all) other switches which are not made by Carling.   Carling toggle switches are used in Fender amps.  Hex outer surface (9/16"), M12 thread for 15/32" bushing.

Part HFN-4

$0.99
(for a pack of 4 nuts)


Click on photo for
larger view
SWITCH, CARLING SPST TOGGLE Original replacement for 60s and 70s Fenderpower and standby switches.   Made by Carling
Part #SW-495
$6.95


Click on photo for
larger view
SWITCH, CARLING SPDT 2-POSITION TOGGLE SWITCH, Original Carling replacement for 60s and 70s Fenderground switch.
Part #SW-494
$9.95


Click on photo for
larger view
SAVE WITH MULTIPACK!  3 SWITCHES: Two CarlingSPST toggle switches and one CarlingSPDT toggle switch. Original replacement for 60s and 70s Fender™ Amps (Power, standby, and ground switches). Change the power,  standby, and ground switches on your Fender™ at the same time, and save!
Part #SW-4945
$20.50


Click on photo for
larger view
FENDER™ 59 BASSMAN REISSUE STANDBY SWITCH   CarlingSPST toggle switch with 1/4" push-on connectors.   Original Fender part number 0036572000.   Mounting nuts are included.
Part #SW-514
$9.95


Click on photo for
larger view
SWITCH, FULL-SIZE TOGGLE HANDLE AND BUSHING, SPST, WITH MINIATURE BODY.   This Revisit™ switch is the solution when you need a full-size toggle switch with long handle, but have limited room on the inside for a large-body switch.   This ingenious switch is full-size on the exterior, but a space-saver inside the enclosure.  Specifications: • Current rating: 6A @ 125 VAC, 3A @ 250 VAC • Contacts: 2 (SPST) • Threaded bushing diameter: 12 mm (15/32") - fits in 1/2 inch hole.   See dimension drawing here.
Part #SW-320
$2.69


Click on photo for
larger view
SWITCH, FULL-SIZE TOGGLE HANDLE AND BUSHING, SPDT, WITH MINIATURE BODY.   This Revisit™ switch is the solution when you need a full-size toggle switch with long handle, but have limited room on the inside for a large-body switch.   This ingenious switch is full-size on the exterior, but a space-saver inside the enclosure.  Specifications: • Current rating: 6A @ 125 VAC, 3A @ 250 VAC • Contacts: 2 (SPDT) • Threaded bushing diameter: 12 mm (15/32") - fits in 1/2 inch hole.   See dimension drawing here.
Part #SW-325
$3.59


Click on photo for
larger view
SWITCH, CARLING DPST PROGRESSIVE TOGGLE (OFF-STANDBY-PLAY)  Replacement for amps which use a single toggle switch for both power and standby.   Or, may be used to engineer a modification to amps which have a toggle power switch switch, but don`t offer a standby switch (such as the Peavey Delta Blues, Fender™ Blues Junior, etc).    See wiring information here.
Part #SW-520
$7.95


Click on photo for
larger view
SWITCH, STANDARD SIZE TOGGLE - Made by Carling - rated at 15A/125VAC, 10A/250VAC. Two position (on/off), single pole (SPST). Fits 1/2" chassis hole. Solder terminals.
Part #SW-526
$4.95


Click on photo for
larger view
SWITCH, TOGGLE - MADE BY CARLING - RATED AT 15A, 125VAC.    Two position (on/off), single pole (SPST).   Fits 1/2" chassis hole.   1/4" push on terminals.     Original Fender™ part number 003703900 (old number 037039).  Made by Carling   Used as the standby switch in the following Fender™ amps:   Vibro-King, Vibrasonic, Tonemaster, Rumble Bas, Prosonic, Hot Rod Deluxe, Hot Rod Deville, Custom Vibrolux, Blues Junior, Blues Deluxe, Blues Deville, Bassman 300, 94 Twin, 65 Twin Reverb Reissue, 65 Deluxe Reverb Reissue, Twin Amp (Pro Tube), Super-Sonic (Head & Combo), 65 Super Reverb Reissue, Pro Junior, Concert Reverb Reissue, 64 Vibroverb Custom, 57 Twin Amp Reissue.
Part #SW-515
$7.95


Click on photo for
larger view
SWITCH, STANDARD SIZE TOGGLE - MADE BY CARLING - RATED AT 15A/125VAC, 10A/250VAC.    Two position (on/off), double pole (DPST).   Fits 1/2" chassis hole.   Solder terminals or 1/4" push on.     Original Fender™ part number 003657000 (old number 036570).   Made by Carling  Used as the power switch in the following Fender™ amps:   Vibro-King, Vibrasonic, Tonemaster, Rumble Bas, Prosonic, Hot Rod Deluxe, Hot Rod Deville, Custom Vibrolux, Blues Junior, Blues Deluxe, Blues Deville, Bassman 300, 94 Twin, 65 Twin Reverb Reissue, 65 Deluxe Reverb Reissue, Twin Amp (Pro Tube), Super-Sonic (Head & Combo), 65 Super Reverb Reissue, Pro Junior, Concert Reverb Reissue, 64 Vibroverb Custom, 57 Twin Amp Reissue, Champion 600 Reissue.
Part #SW-525
$8.95


Click on photo for
larger view
SWITCH, STANDARD SIZE TOGGLE - MADE BY ELECTROSWITCH - RATED AT 6A/125VAC, 3A/250VAC.    Two position (on/off), double pole (DPST).   Fits 1/2" chassis hole.   Solder terminals.  Replacement for many amps which need a 4-terminal DPST style switch with soldered connections.
Part #SW-357
$8.95


Click on photo for
larger view
SWITCH, STANDARD SIZE TOGGLE - RATED AT 15 Amps (125VAC) or 10 Amps (250VAC) - TWO POSITION (ON/ON).   Fits 1/2" chassis hole.   Screw terminals, or remove screws for soldered connections.    Double-pole double-throw, no center off - two positions (ON/ON).
Part #STS-15-DPDT
$4.95


Click on photo for
larger view
SWITCH, STANDARD SIZE TOGGLE - RATED AT 15 Amps (125VAC) or 10 Amps (250VAC) - THREE POSITION (ON/OFF/ON).   Fits 1/2" chassis hole.   Screw terminals, or remove screws for soldered connections.    Double-pole double-throw, with center off - three positions (ON/OFF/ON).
Part #STS-15-DPDT-CO
$5.95


Click on photo for
larger view
MINI ROCKER SWITCH  - MARKED 0-1 FOR ON/OFF
DPST Mini Rocker Switch.  Has 4 electrical terminals on back of switch.   Face of switch marked with "0" and "1" for on/off.   0.5" x 0.75" mounting hole diameter, rated for applications from 8 to 10 amps at 125VAC, DPST with .187" tabs.    Replaces Fender part numbers 025935 and 003928700, used in the following Fender amps:   Bullet Reverb, Bullet 15 DSP, Bassman 25, BXR-100, Roc Pro 700, Roc Pro 1000, Rumble 15, Rumble 25, Rumble 30, Rumble 40, Rumble 75, Rumble 100, Rumble 150, Rumble 350, Rumble 500, Performer 1000, Princeton 112, Princeton 112 Plus, Princeton Chorus, Princeton Chorus DSP, Princeton 650, Princeton 65 DSP, KXR60, KXR100, Frontman 25R, Frontman 15G, Deluxe 112, Deluxe 112 Plus, Deluxe 90, Deluxe 90 DSP, Champion 30, Champion 30 DSP, Acoustasonic 30, Acoustasonic Jr, Acoustasonic Jr DSP, Mustang I, Mustang II, Mustang III, Mustang IV, Mustang V, Super Champ XD.
Part #SW-287
$3.95


Click on photo for
larger view
ROCKER SWITCH, FENDER, EXTRA-LARGE BLACK, DPDT 6 TERMINAL, OUTPUT HI-LO
Extra large Fender rocker switch - has 6 electrical terminals on back of switch (DPDT)   1/4" push-on terminals.   Made for 1.07" H x 0.88" W mounting hole.   Rated 20A @ 125VAC.   15A @ 250VAC.   Commonly found as the Hi-Lo Output Switch on domestic (USA) versions of Fender™ amps from the 80s, including the red knob "The Twin" (known as the "Evil" Twin), and red knob Dual Showman.   Used only for the Hi-Lo Output Switch.  Original Fender™ part number  026480
Part #SW-518
$9.99


Click on photo for
larger view
ROCKER SWITCH, FENDER, EXTRA-LARGE BLACK
Extra large Fender rocker switch - has 4 electrical terminals on back of switch (DPST).   1/4" push-on terminals.   Made for 1.07" H x 0.88" W mounting hole.   Rated 20A @ 125VAC.   15A @ 250VAC.   Commonly found on domestic (USA) versions of Fender™ amps from the 80s through today - including the Pro 185, "Evil" Twin, Super 60, London 185, Super 112, Super 210, Power Chorus, Red Knob Dual Showman, Stage 100, Stage 185, Stage 112SE, Ultimate Chorus, Cyber Champ, Cyber Deluxe, Cyber Twin, SFX Satellite, Bassman 1200, Acoustasonic SFX,  Metalhead MH-500, MB-1200, Steel King, Bassman 100 (PR420), Bassman 200 (PR419), Bassman 400 (PR412), and others.   Used for Power, or Standby.  Original Fender™ part numbers 039236, 026479.   For replacing multiple switches, see multipack below.
Part #SW-517
$7.99


Click on photo for
larger view
ROCKER SWITCH, FENDER, EXTRA-LARGE BLACK, SET OF 2 SWITCHES
Save with our MultiPack!  Extra large Fender rocker switch - has 4 electrical terminals on back of switch (DPST).   1/4" push-on terminals.   Made for 1.07" H x 0.88" W mounting hole.   Rated 20A @ 125VAC.   15A @ 250VAC.   Commonly found on domestic (USA) versions of Fender™ amps from the 80s through today - including the Pro 185, "Evil" Twin, Super 60, London 185, Super 112, Super 210, Power Chorus, Red Knob Dual Showman, Stage 100, Stage 185, Stage 112SE, Ultimate Chorus, Cyber Champ, Cyber Deluxe, Cyber Twin, SFX Satellite, Bassman 1200, Acoustasonic SFX,  Metalhead MH-500, MB-1200, Steel King, Bassman 100 (PR420), Bassman 200 (PR419), Bassman 400 (PR412), and others.   Used for Power, and Standby.    Original Fender™ part numbers 039236 and 026479. This kit of two switches lets you replace both power and standby switches on amps so equipped.
Part #SW-517X2
$13.99
(for a set of two switches)



Click on photo for
larger view
ROCKER SWITCH, LIGHTED POWER, USED IN Fender™ BASSMAN 100, 150 AND 250.  Has 4 electrical terminals on back of switch.   1/4" push-on terminals, or solder directly to terminals.   Rated 20A @ 120VAC.   Needs rectangular cutout of 0.86" wide x 1.18" tall (22mm x 30mm).   Replacement for the discontinued Fender part numbers 0064049000 and 0064050000, used in the Bassman 250, Bassman 150 and the Bassman 100 (the version with a white control panel only).  Internal neon lamp powered by 120VAC.  Not for use on 230VAC.
Part #SW-493F
$10.95


Click on photo for
larger view
ROCKER SWITCH, BLACK.
Has 4 electrical terminals on back of switch (DPST).   Non-lighted.  1/4" push-on terminals, or solder directly to terminals.   Rated 20A @ 125VAC, 16A @ 250VAC.   Needs rectangular cutout of 0.82" wide x 1.15" tall (21mm x 29mm)
Part #SW-5072
$3.95


Click on photo for
larger view
SWITCH, SLIDE, SWITCHCRAFT™, DPDT (6 TERMINALS),  REPLACEMENT FOR BRIGHT SWITCH IN 60s and 70s Fender™ AMPS.   Also used in many other applications, including some Electro Harmonix AC powered effects pedals, such as the Memory Man.  Also used as the slide switch on Jazzmaster and Jaquar guitars.  Used for the power switch in the vintage 60s and 70s Fender Champ, Vibro Champ, and Bronco amps. Rated at 3A, 125VAC.    Click here for physical specifications.   Two screws are included with the switch.
Part #SW-116S - CURRENTLY OUT OF STOCK. NO NEW STOCK EXPECTED FROM SWITCHCRAFT UNTIL JULY, 2022.
$4.95


Click on photo for
larger view
SWITCH, SLIDE, DPDT (6 TERMINALS),  MADE BY ALPHA (TAIWAN), MAY BE USED AS A REPLACEMENT FOR BRIGHT SWITCH IN 60`s and 70`s Fender™ AMPS.   Also used in many other applications, including some Electro Harmonix AC powered effects pedals, such as the Memory Man.  Click here for physical specifications.   Two screws are included with the switch.  See below for a kit of two of these switches with screws included for refurbishing Fender™ amps.
Part #SW-242S
$1.95


Click on photo for
larger view
FOOT SWITCH, CARLING™ BRAND, SPDT
Found in many type of footswitches.  Has 3 electrical terminals (single pole, double throw)Solder lugs for wire.
Part #FS-492
$11.95


Click on photo for
larger view
FOOT SWITCH, CARLING BRAND, SPST, LATCHING, REPLACEMENT FOR Fender™, ETC.
Carling SPST footswitch. Used in Fender™ etc. Reverb/tremolo/channel switching pedals.  Has 2 electrical terminals (single pole, single throw)Solder lugs for wire.
Part #FS-493
$9.95


Click on photo for
larger view
FOOT SWITCH, SPST, LATCHING, FOR SWITCHING AND EFFECTS - Fender™ TYPE.
Has 3 electrical terminals (single pole, single throw)Solder lugs for wire. Commonly found in newer Fender™ footswitch boxes, including the footswitch box for the Vibro-King Custom, 64 Vibroverb Custom, 68 Custom Deluxe Reverb, and 68 Custom Twin Reverb.  Fender™ part number 0024042000.
Part #FS-298
$3.95


Click on photo for
larger view
FOOT SWITCH, 3PDT, PC MOUNT, LATCHING, FOR SWITCHING AND EFFECTS.
Has 9 electrical terminals (3 pole, double throw)    Commonly found in effects pedals which have "true bypass".   Made for PC mounting.
Part #FS-501-PC
$7.95
