Marshall™
Cooling Fans

We carry a complete selection of Marshall™ Amplifier parts for both vintage and modern amps.

Back to Marshall™ Amp Parts Index



Click on photo for
larger view
OUTPUT MODULE FAN - Marshall™ MG SERIES AMPS - PREMIUM TYPE (BALL BEARINGS), HIGH AIRFLOW, LOWER NOISE
Fits many of the Marshall™ MG100DFX, MG100HDFX, MG50DFX and the MG250DFX models.  IMPORTANT NOTE:   Does NOT fit the MG50FX, MG100FX, or MG100HFX models - these are the models with the large "MG" on the front panel.  Check model number carefully.   Note:   Check size of the old fan.   If the old fan is 2" x 2" x 3/8", this is the correct fan.   Some Marshall™ versions of the MG100DFX, MG100HDFX, MG50DFX and the MG250DFX used a larger fan (2 3/8" x 2 3/8" x 1").   If your amp has the larger fan, order the OD6025-12, below.   12 volts DC, 1.10 Watts, 5000 RPM, 11.0 Cubic Feet/Minute Airflow, 26dBA Noise.   Comes with 12" tinned leads - cut off and splice connector from original fan.   Ratings:   Reliability:  A,  Airflow:  A,  Noise:   A-,  Price:   B-
Part #OD5010-12

Installation video for fan:



$19.95


Click on photo for
larger view
OUTPUT MODULE FAN - Marshall™ MG Series PREMIUM TYPE (BALL BEARINGS), HIGH AIRFLOW, LOW NOISE
Fits some versions of the Marshall™ MG100DFX, MG100HDFX, MG50DFX and the MG250DFX models.  IMPORTANT NOTE:   Does NOT fit the MG50FX, MG100FX, or MG100HFX models - these are the models with the large "MG" on the front panel.  Check model number carefully.   Note:   Check size of the old fan.   If the old fan is 2 3/8" x 2 3/8" x 1", this is the correct fan.   Some Marshall™ versions of the MG100DFX, MG100HDFX, MG50DFX and the MG250DFX used a smaller fan (2"  x 2" x 3/8").   If your amp has the smaller fan, order the OD5010-12, above.  12 volts DC, 1.70 Watts, 3500 RPM, 18.0 Cubic Feet/Minute Airflow, 27dBA Noise.    Comes with 12" tinned leads - cut off and splice connector from original fan.   Ratings:   Reliability:  A,  Airflow:  A,  Noise:   B,  Price:  B
Part #OD6025-12
$19.95


Click on photo for
larger view
OUTPUT MODULE FAN - Marshall™ MODE 4 MF350 HEAD - PREMIUM TYPE (BALL BEARINGS), HIGH AIRFLOW, LOW NOISE
Fits only the Marshall™ MF350 Mode 4 350W Head.   60mm x 60mm x 25mm.  24 volts DC, 3.50 Watts, 4500 RPM, 24.0 Cubic Feet/Minute Airflow, 33dBA Noise.   Note:  The MF350 Mode 4 Head has two of these fans.     Comes with 12" tinned leads - cut off and splice connector from original fan.   Ratings:   Reliability:  A,  Airflow:  A,  Noise:   B,  Price:  B
Part #OD6025-24
$19.95


Click on photo for
larger view
OUTPUT MODULE FAN - Marshall™ AVT SERIES AMPS
Fits only the Marshall™ AVT50, AVT100, AVT150 and AVT275 models.  This is the newer style 1cm thick version, which replaces the older style 2cm thick type.  40mm x 40mm x 10mm.  24 volts DC, 1.4 Watts, 6000 RPM, 6.7 CF/M Airflow.   Comes with tinned leads - cut off and splice connector from original fan.
Part #OD4010-24
$10.95


Click on photo for
larger view
Fan Grill, Chrome, 60 mm   Made to fit 60mm fans, such as the OD6025-12 or OD6025-24.   Attaches with the same screws which hold the fan in place.   Limited quantity of this item.

Part #FGC-60
$1.50
