We carry a complete selection of Marshall™ Amplifier parts for both vintage and modern amps.

Back to Marshall™ Amp Parts Index



Click on photo for
 larger view
Marshall™ EARLY INDICATOR LIGHT - 6 VOLT, WITH RETAINER CLIP.
Indicator light, square. 6 Volts.   Measures:  0.44" Length x 0.44" Width x 0.27" Depth.   For 3/8" diameter hole.  Used in vintage Marshall™ designs such as the JMP.   6 volt lamp - designed to run off of the filament voltage line.   Original Marshall™ part.   Retainer clip IS included with the light.   Read about 6V light installation here.
Part #MPL-06
$11.95


Click on photo for
 larger view
Marshall™ EARLY INDICATOR LIGHT - 120 VOLT.
Indicator light, square. 120 Volts. Measures: 0.47" Length x 0.47" Width x 0.09" Depth (3/8" mounting hole).   Used in vintage Marshall™ designs such as the JMP.   120 volt lamp - designed to run off of the switched line voltage. Original Marshall™ part.   No retainer needed on this lamp - has automatic lock-in to 3/8" mounting hole.
Part #MPL-120
$11.95


Click on photo for
 larger view
Marshall™ VINTAGE INDICATOR LIGHT - PURPLE, 6V LED.
Indicator light, square. Purple, LED powered, for 6V only.   As used in the Marshall Vintage Modern models 2266, 2466, and 2266C. Original Marshall™ part M-BULB-00007.
Part #MPL-007
$10.95


Click on photo for
 larger view
Marshall™ VINTAGE AMBER INDICATOR LIGHT - 120 VOLT.
Indicator light, round. 120 Volts.  3/8" mounting hole.   Used in vintage Marshall™ designs such as the JTM-45 and JTM-100 from the early 1960s.  Also found in other vintage British amps.   120 volt lamp - designed to run on the switched line voltage (North America only).   Mounting nut is included.
Part #MPL-6010
$9.95


Click on photo for
 larger view
Marshall™ VINTAGE RED INDICATOR LIGHT - 120 VOLT.
Indicator light, round. 120 Volts.  3/8" mounting hole.   Used in vintage Marshall™ designs such as the JTM-45 and JTM-100 from the early 1960s.  Also found in other vintage British amps.   120 volt lamp - designed to run on the switched line voltage (North America only).   Mounting nut is included.
Part #MPL-6010R
$9.95


LED Colors Available:

Click on photo for
larger view
5mm DIFFUSED LED - CHOICE OF COLORS
Standard 5mm (3/16") diameter diffused LED found in many guitar amplifiers and effects pedals.  Available in white, red, blue, green, or yellow.   This 5mm size is commonly called the T-1-3/4 size.  On LEDs the longer leg (the anode) goes to the positive voltage supply.   LEDs need a DC supply voltage and a resistor in series with them to limit current.   For a 9V supply, a 470 ohm resistor works well.   For 12 volts, a 680 ohm resistor, and for 15 volts, a 1K resistor.

Part #LED-5D
$0.59
(per LED)


Select Option:


Quantity:


LED Colors Available:

Click on photo for
larger view
3mm DIFFUSED LED - CHOICE OF COLORS
Standard 3mm (1/8") diameter diffused LED found in many guitar amplifiers and effects pedals.  Available in white, red, blue, green, or yellow.   This 3mm size is commonly called the T-1 size.  On LEDs the longer leg (the anode) goes to the positive voltage supply.   LEDs need a DC supply voltage and a resistor in series with them to limit current.   For a 9V supply, a 470 ohm resistor works well.   For 12 volts, a 680 ohm resistor, and for 15 volts, a 1K resistor.

Part #LED-3D
$0.39
(per LED)


Select Option:


Quantity:


Click on photo for
larger view
SUPER-BRIGHT 5mm RED WATERCLEAR LED
Standard 5mm (3/16") diameter waterclear red LED found in many guitar amplifiers and effects pedals.   A red waterclear LED looks clear when it is off, and emits a bright red light when power is applied.  On LED's the longer leg (the anode) goes to the positive voltage supply.   LED's need a DC supply voltage and a resistor in series with them to limit current.   For a 9V supply, a 470 ohm resistor works well.   For 12 volts, a 680 resistor resistor, and for 15 volts, a 1K resistor.

Part #LED-5R-WC
$0.59


LED Colors Available:

Click on photo for
larger view
BEZEL-MOUNTED LED WITH BUILT-IN RESISTOR
The ultimate time saver!  This is an LED mounted in a bezel with a resistor and shrink wrapped wires.
Length is 19mm long - 16mm of which is below the mounting area.  These Prewired LEDs are designed for 8V to 12V DC - no dropping resistor needed.   The length of the wire is about 6.5"   Mounting hole is 8mm, LED color choice is red, amber, green, blue or white.
Part #LED-725-X
$1.95

Select Option:


Quantity:
