Peavey Semiconductors, Capacitors & Electronics

Click on photo for
larger view
CAPACITOR, electrolytic 3300uF @ 63V with radial snap-in leads.  Made by Panasonic.   Dimensions:  30mm x 30mm

Part #RAD-3300-63
$5.95


Click on photo for
larger view
CAPACITOR, TALL, NARROW.   Electrolytic 4700uF @ 63V with radial snap-in leads.  Made by Cornell Dubilier. Good replacement for the 5000uF/55V radial capacitors used in several Peavey Amp models.    Measures 1.00" across X 1.6" tall.  (25mm x 40mm)

Part #RAD-4700-63-TN
$6.95


Click on photo for
larger view
CAPACITOR, SHORT, WIDE.   Electrolytic 4700uF @ 63V with radial snap-in leads.  Made by Nichicon. Good replacement for the 5000uF/55V radial capacitors used in several Peavey Amp models.    Measures 1.19" across X 1.22" tall.

Part #RAD-4700-63-SW
$5.95





Op-Amp, 4558, very common in amplifiers, mixers, power amps.  8-pin DIP
Part #NJM4558-D
$1.00

Low-noise 5532 Dual Op-Amp in 8-pin DIP package.
Part #NE5532
$1.50

Low-noise 5534 Single Op-Amp in 8-pin DIP package.
Part #NE5534
$1.50

Low-noise 2068 Dual Op-Amp in 8-pin DIP package.
Part #NJM2068
$1.50

Low-current, JFET input, TL062 Dual Op-Amp in 8-pin DIP package.   Compatible with TL072 designs, with significantly lower current draw.   Good choice for battery-operated pedals to increase battery life.
Part #TL062
$1.00

Low-noise, JFET input, TL071 Single Op-Amp in 8-pin DIP package.  Also TL071CN.
Part #TL071CP
$1.50

Low-noise, JFET input, TL072 Dual Op-Amp in 8-pin DIP package.  Also TL072CN.
Part #TL072CP
$1.60

High slew rate, JFET input, TL082 Dual Op-Amp in 8-pin DIP packag
Part #TL082
$1.90


4808-3004
From the 3M Company ... 8-pin DIP socket, fits all of the 8-pin op-amps above.   We recommend installing a socket first whenever you replace an op-amp - it makes future repairs much quicker and easier!
Part #4808-3004
$0.35

+15V 1 amp Voltage Regulator - Metal Tab
Part #7815
$0.90

-15V 1 amp Voltage Regulator - Metal Tab
Part #7915
$0.90



Speaker Protector Lamps



Click on photo for
larger view
1141 Speaker Protection Limiter Lamp
This lamp is used in many crossovers for medium sized horn drivers - this size is commonly found in Peavey.   As the audio power increases, this device heats up (and even lights up at high power levels).  As it heats its resistance increases, thereby reducing the audio power reaching the driver.   This lamp fits a standard automotive style twist receptacle on the crossover board.
Part # 1141
$1.49


Click on photo for
larger view
1156 Speaker Protection Limiter Lamp
This lamp is used in many crossovers for larger sized horn drivers - this size is commonly found in Peavey.   As the audio power increases, this device heats up (and even lights up at high power levels).  As it heats its resistance increases, thereby reducing the audio power reaching the driver.   This lamp fits a standard automotive style twist receptacle on the crossover board.
Part # 1156
$1.49
