Peavey Switches

Click on photo for
larger view
FOOT SWITCH, CARLING® BRAND, SPDT
Found in many type of footswitches.  Has 3 electrical terminals (single pole, double throw)Solder lugs for wire.
Part #FS-492
$11.95


Click on photo for
larger view
FOOT SWITCH, CARLING BRAND, SPST, LATCHING, REPLACEMENT FOR Fender®, ETC.
Carling SPST footswitch. Used in Marshall® etc. Reverb/tremolo/channel switching pedals.  Has 2 electrical terminals (single pole, single throw)Solder lugs for wire.
Part #FS-493
$9.95


Click on photo for
larger view
FOOT SWITCH, DPDT, LATCHING, PC MOUNT, FOR SWITCHING AND EFFECTS.
Electrically equivalent and physically the same body size as the FS-498, but made for direct connection to a PC board.  Found in the Line 6® XPS-AB power supply for their Variax guitars.  Has 6 electrical terminals (double pole, double throw).
Part #FS-498-PC

(Also see our complete line of switches)

$3.95


Click on photo for
larger view
MINI ROCKER SWITCH, PEAVEY STYLE
Carling miniature rocker switch, SPST with .187" tabs (Peavey Style). 0.51" x 0.76" mounting hole diameter, 5A, 125 VAC
Part #SW-560
$3.95


Click on photo for
larger view
MINI ROCKER SWITCH, PEAVEY
Carling miniature rocker switch, SPST with .187" tabs (Peavey Style). 1/2" x 3/4" mounting hole diameter, 5A, 125 VAC.   Used in the Peavey Classic VTX amp, VTX Series MX, Heritage VTX from the 1980s.
Part #SW-507
$3.95


Click on photo for
larger view
ORIGINAL Peavey® PUSH SWITCH
DPDT Mini Short-Throw Push Switch.  Has 12 electrical terminals on bottom of switch (2XDPDT).  Used for front panel switches on Peavey® Supreme Transtube Amps.  Original Peavey® part number 71322256 or 31322256.
Part #SW-256
$9.95


Click on photo for
larger view
ORIGINAL Peavey® CHANNEL SELECT TOGGLE SWITCH
2P3TSP Toggle Switch used for the front panel channel select switch on the Triple XXX and Triple XXX II amp series.  Used as the resonance switch in the Ultra 112, Ultra 212, Ultra 410 combos and Ultra Plus head.  Original Peavey® part number 71322368 or 31322368.
Part #SW-236

This switch has been discontinued by Peavey - See the SW-236A, below




REVISIT CHANNEL SELECT TOGGLE SWITCH FOR Peavey®
2P3TSP Toggle Switch used for the front panel channel select switch on the Triple XXX and Triple XXX II amp series.  Used as the resonance switch in the Ultra 112, Ultra 212, Ultra 410 combos and Ultra Plus head.  Replaces original Peavey® part number 71322368 or 31322368.
Part #SW-236A
$4.95




Click on photo for
 larger view

REVISIT 3-POSITION SLIDE SWITCH FOR Peavey®
2P3T Slide Switch used for Impedance, Power Level, or Damping on the back panel of several Peavey® amps.  Found in the Peavey Windsor Studio, 6505 112 Combo, Joe Satriani JSX, ValveKing 212 Combo, ValveKing Head, 5150-II, and XXL models.  Replaces original Peavey® part number 71322328 or 31322328.   Mounting hardware included
Part #SW-313
$7.95


Click on photo for
larger view
SWITCH, CARLING® SPST TOGGLE Original replacement for  70s power and standby switches.   Made by Carling®
Part #SW-495
$6.95


Click on photo for
larger view
FULL-SIZE TOGGLE SWITCH, CARLING®, DPDT

Carling, DPDT 2 position toggle with solder lugs (6A, 125V). 6 Solder Lugs - 2 on each end, and 2 on the bottom (common lugs).   0.687" toggle length. On-On (no center position).

Part #SW-527
$9.95


Click on photo for
larger view
SWITCH, FULL-SIZE TOGGLE HANDLE AND BUSHING, SPST, WITH MINIATURE BODY.   This Revisit™ switch is the solution when you need a full-size toggle switch with long handle, but have limited room on the inside for a large-body switch.   This ingenious switch is full-size on the exterior, but a space-saver inside the enclosure.  Specifications: • Current rating: 6A @ 125 VAC, 3A @ 250 VAC • Contacts: 2 (SPST) • Threaded bushing diameter: 12 mm (15/32") - fits in 1/2 inch hole.   See dimension drawing here.
Part #SW-320
$2.69


Click on photo for
larger view
SWITCH, FULL-SIZE TOGGLE HANDLE AND BUSHING, SPDT, WITH MINIATURE BODY.   This Revisit™ switch is the solution when you need a full-size toggle switch with long handle, but have limited room on the inside for a large-body switch.   This ingenious switch is full-size on the exterior, but a space-saver inside the enclosure.  Specifications: • Current rating: 6A @ 125 VAC, 3A @ 250 VAC • Contacts: 2 (SPDT) • Threaded bushing diameter: 12 mm (15/32") - fits in 1/2 inch hole.   See dimension drawing here.
Part #SW-325
$3.59


Click on photo for
larger view
SWITCH, CARLING DPST PROGRESSIVE TOGGLE (OFF-STANDBY-PLAY)  Replacement for amps which use a single toggle switch for both power and standby.   Or, may be used to engineer a modification to amps which have a toggle power switch switch, but do not offer a standby switch (such as the Peavey Delta Blues, Fender® Blues Junior, etc).    See wiring information here.
Part #SW-520
$7.95


Click on photo for
larger view
SWITCH, STANDARD SIZE TOGGLE - Rated at 20 Amps (125VAC) or 15 Amps (250VAC).   Fits 1/2" chassis hole.   Solder terminals or 1/4" push on, single pole / single throw (SPST).   Two position - on/off.  NOTE:   RATED FOR AC SERVICE ONLY AT 250V MAX - DO NOT USE AS A GUITAR AMPLIFIER STANDBY SWITCH.
Part #STS-20
$3.95


Click on photo for
larger view
SWITCH, STANDARD SIZE TOGGLE - MADE BY CARLING - RATED AT 15A/125VAC, 10A/250VAC.    TWO POSITION (ON/OFF), DOUBLE POLE (DPST).  FITS 1/2" CHASSIS HOLE.  SOLDER TERMINALS OR 1/4" PUSH-ON.  Fender® PART NUMBER 0036570000.
Part #SW-525
$8.95


Click on photo for
larger view
SWITCH, STANDARD SIZE TOGGLE - Made by Carling® - rated at 15A/125VAC, 10A/250VAC. Two position (on/off), single pole (SPST). Fits 1/2" chassis hole. Solder terminals.
Part #SW-526
$4.95


Click on photo for
larger view
SWITCH, STANDARD SIZE TOGGLE - RATED AT 15 Amps (125VAC) or 10 Amps (250VAC) - TWO POSITION (ON/ON).   Fits 1/2" chassis hole.   Screw terminals, or remove screws for soldered connections.    Double-pole double-throw, no center off - two positions (ON/ON).
Part #STS-15-DPDT
$4.95


Click on photo for
larger view
SWITCH, STANDARD SIZE TOGGLE - RATED AT 15 Amps (125VAC) or 10 Amps (250VAC) - THREE POSITION (ON/OFF/ON).   Fits 1/2" chassis hole.   Screw terminals, or remove screws for soldered connections.    Double-pole double-throw, with center off - three positions (ON/OFF/ON).
Part #STS-15-DPDT-CO
$5.95
